Application of Virtual Prototyping Technology on Kinematical Simulation of Baler Compression Device

Abstract:

Compression device is the important mechanism of baler. This paper uses the virtual prototyping technology. It analyzes the function of compression device in 9KG-350 high density baler and the three-dimensional digital model of compression device is obtained based on UG package .Then the model is put into ADAMS, and a kinematical simulation analysis is performed. Through the simulation, the whole kinematical process is reflected, gaining the relative kinematical curves of compression device as well. The results can be help in study the design of baler and the structure optimization.

• Periodical: Advanced Materials Research (Volumes 591-593)
• Pages: 644-647
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.591-593.644
• Online since: November 2012
• Authors: Xue Fei Zheng, Bi Wen Li, Ying Zhang
• Keywords: Baler, Compression Device, Kinematical Simulation, Virtual Prototyping Technology

References

[1] L.P. Chen:Mechanical System Dynamics Analysis and ADAMS Application Tutorial (Beijing: Tsinghua University Press, China 2005.),p.3

[2] X.H. Song :Kinematics Simulation and Virtual Prototyping of Mechanical Presses(MS.Zhejiang University, China 2005.),p.38

[3] J.M.Du.:Rheological Study of the Fresh Grass Material Compression Process(ph.D.Inner Mongolia Agricultural University, China 2005.),p.17

[4] J. Li, Y.Z. Tao:MSC.ADAMS FSP BasicTraining Course(. Beijing: Tsinghua University Press, China 2008.),p.132
