Structure Research on Carrying Frame in Portable Exoskeleton Make by Polyphenylene Sulfide

Abstract:

As carrying frame make by Polyphenylene Sulfide in Portable Exoskeleton to the research object, establish the 3D model of carrying frame on the basis of the configuration parameters of Human body backside, and implement the strength and stiffness analysis through the ANSYS software. The analysis is divided into three portions in accordance with working conditions, bending with no support, bending with human support and swaying with human support. Thereinto three portions have the same payload as 45kg and the same bending range attains 45 degree. Ultimately Stress value, quantity and distribution chart of the deformation have been obtained for each portion. Analysis results show that the each direction deformation Maximum and the stress Maximum of the carrying frame which bend without support present linear growth along with the increase of the bending angle in the course of the bending over. Therefore it causes the larger concentration of stress and deformation in the carrying frame and causes the additional load in the body. So the working conditions for carrying frame should be avoided which bend without support. To the rest of the two conditions, the stress and deformation of carrying frame are small enough to be meeting the use requirements.

• Periodical: Advanced Materials Research (Volumes 591-593)
• Pages: 96-101
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.591-593.96
• Online since: November 2012
• Authors: Fang Liu, Wen Ming Cheng, Yi Zhou
• Keywords: Carrying Frame Structure Design, Finite Element Calculation, Human Support, Portable Exoskeleton

References

[1] Huo Y, Li Z. Mechanism design and simulation about the exoskeleton intelligence system. 2009 IEEE International Conference on Intelligent Computing and Intelligent Systems, ICIS 2009, November 20, 2009 - November 22, 2009. Shanghai, China: IEEE Computer Society; 2009. pp.551-6.

DOI: 10.1109/icicisys.2009.5358350

[2] Kazerooni H, Steger R. The Berkeley Lower Extremity Exoskeleton. Journal of Dynamic Systems, Measurement, and Control 2006,128(1):14-25.

DOI: 10.1115/1.2168164

[3] Monnet J, Saito Y, Onishi K. Exoskeleton robot using hydraulic Bilateral Servo Actuator system for non-ambulatory person's transfer. IASTED International Conference on Biomedical Engineering, Biomed 2011, February 16, 2011 - February 18, 2011. Innsbruck, Austria: Acta Press; 2011. pp.234-41.

DOI: 10.2316/p.2011.723-044

[4] Zoss A, Kazerooni H, Chu A. On the Mechanical Design of the Berkeley Lower Extremity Exoskeleton (BLEEX). IEEE International Conference on Intelligent Robots and Systems2005. pp.3465-72.

DOI: 10.1109/iros.2005.1545453

[5] Zoss AB, Kazerooni H, Chu A. Biomechanical Design of the Berkeley Lower Extremity Exoskeleton (BLEEX). IEEE/ASME Transactions on Mechatronics. 2006,11(2):128-38.

DOI: 10.1109/tmech.2006.871087

[6] Zhang Guangpeng. Ergonomics Principle And Application. Beijing: Mechanical Industry Press;2008.

[7] Jiang Shengling, Gu Xiaoyu, Zhang Zhiyuan. Dynamic Mechanical Properties of Poly(phenylene sulfide)/Hydroxyl Purified Multi-walled Carbon Nanotubes Composites. Journal of Materials Engineering. 2011,06:77-80.

[8] Wu Lanfeng, Wu Defeng, Zhang Ming. Electrical and Mechanical Properties of Poly(Phenylene Sulfide)/Carbon Nanotubes Composites. Polymer Materials Science & Engineering. 2009,08(25):36-39.

[9] Luo Yan, Gao Qing. Finite Element Implementation of Damage-Coupled Time-Dependent Fatigue Failure Model. Journal of Southwest Jiaotong University. 2012,04(47):230-235.
