The Abnormal Vibration Source Analysis of Automobile Drive Axle

Abstract:

Through a Transmission bench test of a certain automobile Drive axle Assembly ,the abnormal vibration in Rear axle can be found. This paper establishes three demensions modle and Finite element model of the Rear Drive axle Assembly and calculates the modal of the Assembly and Axle housing respectively. It can be found that the frequency of the abnormal vibration in the Rear axle Bench test Coincides with the frequence of the Assembly First-order bending.It presents that it is the Assembly Resonance that leads to the abnormal vibration of Rear axle,not just Axle housing Resonance
