The Study of Surface Modification 304 Stainless Steel in Simulated PEMFC Environments

Abstract:

In order to increase the corrosion resistant and reduce the interfacial contact resistance of the stainless steel, the duplex treatment technology of electroplating Cr and plasma-assisted nitriding process for AISI 304SS is exploited. X-ray diffraction (XRD), scanning electron microscopy (SEM) and the electrochemical tests such as potentiodynamic and potentiostatic polarization in the simulation PEMFC environments are measured. XRD showed that the surface layer of the 540 ° C and 550 ° C were Cr and Cr2N; the 580 °C was the CrN and Cr₂N. The nitride sample of the 550 °C could see the closure process of the mesh crack. Compared with the simulated PEMFC anode environment, higher corrosion resistance was showed in the simulated PEMFC cathode environment. The current density of the 540°C, 550°C and 580°C samples were negative at the operating potential -0.1V, which would provide cathodic protection to the metallic bipolar plates. In the simulated cathode environment, the current densities of the three samples were quickly stabilized, the surface quickly formed a stable passive film.

• Periodical: Advanced Materials Research (Volumes 608-609)
• Pages: 865-869
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.608-609.865
• Online since: December 2012
• Authors: Jian Li Wang, Hui Yun Shi
• Keywords: 304 Stainless Steel, Corrosion Resistance, PEMFC, Surface Modification

References

[1] R.J. Tian, J.C. Sun: J Power Sources Vol 194 (2009), p.981

[2] S.H. Lee, J.H. Kim et al: J Power Sources Vol 187 (2009), p.312

[3] R.A. Antunes, M.C. Oliveira, Ett G, Ett V: Inter J Hydrogen Energy Vol 35 (2010),p.3632

[4] Y.H. Yun: Inter J Hydrogen Energy Vol 35(2010), p.1713

[5] A. K. Iversen: Corros. Sci Vol 48 (2006), p.1036

[6] H.Wang, J.A. Turner: J. Power Sources Vol 128 (2004), p.193

[7] M. P. Brady, H.l. Wang, Irene Paulauskas et al: Fuel Cell, Vol 2503(2004), p.437

[8] M.P. Brady, K. Weisbrod, I. Paulauskas et al:,Scripta Materialia Vol 50(2004), p.1017

[9] H. Wang, M.P. Brady, G. Teeter et al: J Power Sources Vol 138(2004), p.86

[10] L. Wang, D.S. Kim, K.S. Nam et al: Surf. Coat. Technol. Vol 190(2005), p.151

[11] J.L. Wang, J.C. Sun et al: Inter J Hydrogen Energy Vol. 37 (2012), p.1140
