Magnetic Field Analysis of a Complex Construction Transformer Using Direct Field-Circuit Coupling Method

Abstract:

This paper deals with the main magnetic field distribution for a three-phase five-column disintegration transformer with the iron core disassembled into several parts owing to limited transport condition. The finite element method is employed to solve such a special configuration transformer, in which the direct field-circuit coupling formulation is derived and programmed by APDL programming language. The calculation results, such as the magnetic field distribution in transformer core, the exciting current magnitude and no-load loss are investigated. The optimum size of air gap between each separated iron core limbs is discussed.

• Periodical: Advanced Materials Research (Volumes 614-615)
• Pages: 1230-1233
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.614-615.1230
• Online since: December 2012
• Authors: Yan Li Zhang, Ning Zhang*, Ya Hua Kang, Xiu Ke Yan, De Xin Xie
• Keywords: Disintegration Transformer, Field-Circuit Coupling, Main Magnetic Field

References

[1] Vencislav Cekov Valchev, Alex Van den Bossche. Inductors and Transformers for Power Electronics[M]. CRC Press, 2005.

DOI: 10.1201/9781420027280

[2] J. Jin. The Finite Element Method in Electromagnetics[J]. New York: Wiley, 2000.

[3] Dexin Xie. Engineering electromagnetic field numerical analysis and synthesis[M]. Beijing: Mechanical Industry Press, 2008: 247-259.
