Modeling and Research on the Electromagnetic Field of UHV Autotransformer Using Finite Element Method

Abstract:

With the rapid development of economy and construction of large-scale hydropower, thermal power and nuclear power base, the demand of long-distance, high-capacity transmission of UHV (ultra high voltage) is increasing in China. This paper presents the application of finite element method (FEM), software ANSYS in the magnetic field of core about single-phase three-winding 750KV autotransformer with the next column excitation regulator device. As most driving sources applied to transformers are voltage sources, field-circuit coupling method is generally used in solving electromagnetic field of transformers, so this paper is written to verify if the simulation results are similar to the qualification and to prove the correctness of the method and the practical value.
