Research of the Undervoltage Tripper with Overvoltage Protection Function

Abstract:

The undervoltage tripper is a protection accessory of the low voltage apparatus and can turn off the circuit-breaker automatically when the power occurs lowering out off the given range. As a result of electrical network quality and manufacture procedure and so on, the failure rate of the circuit-breaker’s undervoltage tripper is high and always solved difficultly. This paper proposes one kind of adaptive undervoltage tripper with overvoltage protection function. It can adapt the supply voltage change automatically, absorb overvoltage, block the undervoltage tripper’s coil voltage, cause the operating region of the undervoltage tripper without high voltage dead area and improve the circuit-breaker work’s reliability.

• Periodical: Advanced Materials Research (Volumes 614-615)
• Pages: 1201-1204
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.614-615.1201
• Online since: December 2012
• Authors: Chang Chun Chi*, Lin Fang Hu, Yi Wu
• Keywords: Adaptive, Overvoltage, Reliability, Undervoltage Tripper

References

[1] Changchun Chi. A Mathematical Model For Dynamic Ovel-1oad Protection Based On The Heat Balance Differential Equation [A]. In: International Conference on Image Processing and Pattern Recognition in Industrial Engineering[C]. Xian, China, 2010：Proc.of SPIE Vo1 7820 78203Q-1~7.

DOI: 10.1117/12.867201

[2] Kui Li, Jingqin Wang, Wenhua Li, et al. Study On Reliability for Overload Relay [A]. In: 1st International Conference on Reliability of Electrical Products and Electrical Contacts[C]. Suzhou, China, 2004：228-232.

[3] Junsheng Cheng, Yu Dejie, Yang Yu. Application of an impulse response wavelet to fault diagnosis of rolling bearings [J], Mechanical Systems and Signal Processing，2005,9:1-10.

DOI: 10.1016/j.ymssp.2005.09.014

[4] Peng Zhao, Zhengxin Chen, Yingzi Zhou. Design of Under Voltage Release in Air Circuit Breaker [J], Low Voltage Apparatus, 2010, 21: 13-16.

[5] Hao Zhang, Changchun Chi. Calculation About the Amplitude Value of Fundamental Component of Current in the Distribution Line on Wavelet Analysis [J], Electrotechnics Electric,2009,3:1-3,8.

[6] Anyue Zhou. Intelligent Release of Moulded Case Circuit Breaker Based on Micro Controller Unit Control [J], Low Voltage Apparatus, 2011, 14: 13-16.

[7] Weiming Tong, Zhongwei Li, Wenli Ni. Study of an intelligent low-voltage integrative motor protector based on PIC16F876 single chip [J], RELAY, 2005, 33(3): 43-46.

[8] Yongzhong Wang. Design Optimization of Under Voltage Release for Circuit Breaker [J], Low Voltage Apparatus, 2012, 2: 17-19.

[9] Kena Chen, Haoyong Song, Xingwen Li, Degui Chen. Modeling and Simulation Analysis of Interruption Process of Miniature Circuit Breaker [J],  Low Voltage Apparatus, 2011, 16: 1-5,9.

DOI: 10.1049/cp.2012.0657
