Research on Digital Control of Tension Servo System Based on PLC

Abstract:

Mathematical model of tension servo system drived by two induction motor is analyzed in this paper. Then, structure optimized of first-order active disturbance rejection control (ADRC) of tension servo system is designed. Double channels compensation of extended state observer is used to estimate and compensate the total disturbance of system, and approximate linear and determined treatment is done to the tension control system. S7-300 PLC is used as lower computer controller, while WinCC is used as upper computer monitor software, realizing all-digital control of the system. The experiments is carried on based on S7-300 PLC experimental platform and the results prove that the decoupling control of speed and tension is realized, and the control system has higher dynamic, static status and robustness performances.

• Periodical: Advanced Materials Research (Volumes 614-615)
• Pages: 1445-1448
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.614-615.1445
• Online since: December 2012
• Authors: Chong Chen, Guo Wen Hu
• Keywords: ADRC, Decoupling Control, Digital Control, Servo System, Speed, Tension

References

[1] Seung-Ho Song, and Seung-Ki Sul. IEEE Transactions on industry applications, Vol.36(1998), p.2225

[2] Jingqing Han. Industrial Electronics, Vol. 56 (2009), p.900. (In Chinese)

[3] Jingqing Han. Frontier Science, Vol. 1 (2007), p.24. (In Chinese)

[4] Xianzhong Dai, Guohai Liu. Chinese Electrical Engineering Journal, Vol. 25 (2005), p.109. (In Chinese)
