Coupled Heat Transfer Analysis of Piston Crown, Piston Rings and Cylinder Liner

Abstract:

MAN Diesel’s 6S50MC-C disel is a two-stroke marine diesel engine. As the boundary conditions of temperature field distribution, the mean temperature and mean heat transfer coefficient are calculated firstly. The coupled heat transfer of piston crown, piston rings and cylinder liner are analyzed. The steady temperature field and the transient heat transfer under starting condition of diesel engine are obtained in ANSYS. Maximum temperature is 413.55°C in the top surface edge of the piston crown. 59.5% of the total heat from high-temperature fuel gas heat is absorbed by the cooling oil. The temperature of piston crown is effectively reduced by shaker cooling. The load of diesel engine should be increased slowly to prevent stress concentration. To reduce the destructive effect, enhancing cooling and warming up the main engine are requested.

You might also be interested in these eBooks

Advances in Power and Electrical Engineering

View Preview

Info:

Periodical:

Advanced Materials Research (Volumes 614-615)

Pages:

204-207

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.614-615.204

Citation:

Cite this paper

Online since:

December 2012

Authors:

Ji Wu, Shu Lin Duan, Zhan Hua Wu, Li Dui Wei, Hui Xing

Keywords:

Coupled Heat Transfer, Cylinder Liner, Piston Crown, Piston Ring, Temperature Field

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] Yong Liu, R. D. REITZ. Modeling of heat conduction within chamber walls for multidimensional internal combustion engine simulations. International Journal of Heat and Mass Transfer, 41 (1998), pp.859-869.

DOI: 10.1016/s0017-9310(97)00178-6

Google Scholar

[2] Rui-song Lu, Fa-sen Lin, Rui Zhang.Heat transfer and thermal load of the internal combustion engine. National Defense Industry Press. Bei Jing 1985.

Google Scholar

[3] C Fieberg, R Kneer.Determination of thermal contact resistance from transient temperature measurements. International Journal of Heat and Mass Transfer. 51 (2008), pp.1017-1023.

DOI: 10.1016/j.ijheatmasstransfer.2007.05.004

Google Scholar

[4] Jukka Tiainen, Ilari Kallio, Antti Leino et al. Heat Transfer Study of a High Power Density Diesel Engine. SAE Paper 2004-01-2962, 2004.

DOI: 10.4271/2004-01-2962

Google Scholar

[5] Ekrem Buyukkaya, Muhammet Cerit.Thermal analysis of a ceramic coating diesel engine piston using 3-D finite element method. Surface and Coatings Technology, 202(2007), pp.398-402.

DOI: 10.1016/j.surfcoat.2007.06.006

Google Scholar

[6] M I Karamangil, O Kaynakli, A Surmen.Parametric investigation of cylinder and jacket side convective heat transfer coefficients of gasoline engines. Energy Conversion and Management, 47(2006), pp.800-816.

DOI: 10.1016/j.enconman.2005.05.018

Google Scholar
