Finite Element Analysis of the Pillar of Serf-Motion Assistanced Powered Support Equipment for Tunneling Machine Based on ANSYS

Abstract:

Serf-motion Assistanced Powered Support Equipment for Tunneling Machine is a new underground temporary support equipment .It's using with tunneling machine, whose main aim is to supply temporary support for the heading face, so ensures continuous working of tunneling machine，To ensure continuous operation of the boring machine, To ensure Mechanized operations of the temporary support of machine digging tunnel. Establish the pillar model by using PRO /E, then Import into ANSYS. Doing The stress analysis for the pillar of Serf-motion Assistanced Powered Support Equipment for Tunneling Machine，and then it could verify that Equipment analysis is correct by ANSYS .

• Periodical: Advanced Materials Research (Volume 619)
• Pages: 127-130
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.619.127
• Online since: December 2012
• Authors: Li Jun Luan, Mu Jia Ma, Xin Yue Gu, Jian Feng Qi, Hai Long Xu, Li Ze Yao
• Keywords: Finite Element Method (FEM), Pillar, Serf-Motion Assistanced Powered Support Equipment for Tunneling Machine, Simulation

References

[1] Zhang wei-ping，Li hui. Dig in mining face temporary support equipment present situation and development. [J]. Coal Mine Machinery，1998，（8）：3-4.

[2] Li zhi-qiang，Wang shupu，Li bian-rong . Heading face temporary support equipment present situation and development [J] . Coal Science and Technology，1997，（9）: 41-44.

[3] Wang chun-hua，Sang sheng-yuan，Zhu dian-ye. Based on ANSYS finite element analysis of hydraulic support structure [J]. Coal Mine Machinery，2008，(2): 58-60.

[4] Sun Xun-fang, etc. Material mechanics [M]. Beijing: higher education press，1995（2000 reprint）.
