Application of Co-Simulation in Noise and Vibration Analysis of Shearer

Abstract:

In order to investigate the noise and vibration characteristics of shearer, through the analysis of shearer found that the nonlinear instantaneous impact loading caused by cutting pick in the cutting process is the main disturbance source of the noise and vibration,the simulation pro- gramme of cutting pick momentary load was worked out by the implementation of MATLAB. The vibration of the key parts was obtained through the analysis of the rigid-flex coupled model of shearer which was established based on a co-simulation virtual prototype frame,and found that the vibration of the shell stretched out side is more severe, the shell subjacent ear under a larger dynamic stress, the planet carrier has a evident torsional deformation. According to analysis results, the optimized shell vibration significantly weakened, mechanical performance improved drama- tically. The analysis results provide an important basis for improving the shearer cutting unit design and reducing the noise level of coal face.

You might also be interested in these eBooks

Hydraulic Equipment and Support Systems for Mining

View Preview

Info:

Periodical:

Advanced Materials Research (Volume 619)

Pages:

172-175

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.619.172

Citation:

Cite this paper

Online since:

December 2012

Authors:

Li Juan Zhao, Zhen Tian

Keywords:

Co-Simulation, Noise, Optimization Design, Shearer, Vibration Characteristics

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] Hailan Zhang. Theoretical acoustics[M]. Beijing: Higher education press, (2007).

Google Scholar

[2] Xiaohuo Li, Jiquan Yao. Mathematic model of relation of shearer parameters to noise on coal face[J]. Journal of Heilongjiang Institute of Science & Technology, 2006, 16(5): 282-284.

Google Scholar

[3] Runfang Li, Jianjun Wang. Dynamics of gear system-vibration, shock, noise [M]. Beijing: Science Press, (1997).

Google Scholar

[4] Lijuan Zhao, Cheng-yun Wang. Research on modal parameters identification and vibration analysis of complexed rigid-flex coupled system[J]. Manufacturing Automation, 2009, 31(4): 105-108.

Google Scholar

[5] Lijuan Zhao, Mengmeng Dong. Load problems of working mechanism of the shearer in containing pyrites and thin coal seam[J]. Journal of China Coal Society, 2009, 34 (6): 840-844.

Google Scholar
