Electrode Feeding Speed Control and Experiment Research of ESR Furnace Based on S Style Control Curve

Abstract:

The electrode feeding mechanism and the feeding speed control system of the electroslag remelting furnace are studied. The electrode feeding mechanism is designed based on the electro-hydraulic proportional control technique, and the mechanism’s three-dimensional model is established. The electrode feeding mechanism’s electro-hydraulic proportional control system is simulated. The basic feeding speed model and the error-correction feeding speed model are established; and the S style speed control curve of the electrode feeding system is designed. Experiments were carried out; the system control curves and the experimental production dissection results were obtained. It was found that, the electrode feeding system and the feeding speed control system studied in this paper met the craft procedure and technique requirements of large electroslag remelting furnace, and the method’s validity was verified.

• Periodical: Advanced Materials Research (Volume 619)
• Pages: 480-484
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.619.480
• Online since: December 2012
• Authors: Chang Zhou Wang, Jin Chun Song
• Keywords: Electrode Feeding Mechanism, Electro-Hydraulic Proportional Control System, Electroslag Remelting, Experiment Research, Feeding Speed Control

References

[1] Z. B. Li. Electroslag Metallurgy Principle and Application. Beijing: Metallurgical Industry Press. (1996).

[2] G. Hoyle. Electroslag Processes Principle and Practice. London & New York: Applied Science Publishers (1983).

[3] B. I. Modovar, V. F. Demchenko, et al. Temperature Fields of Large ESR Slab Ingots. Mechanical Engineering Transactions-Institution of Engineers, Australia (1977), pp.153-156.

[4] C. Ernet. International European Conference on Tooling Materials. Schweiz (1982).

[5] G. Stein. Industrial Manufacture of Massively Nitrogen Alloyed Steels in a Pressure ESR Furnace, Steel Times. Vol. 217(3) (1989), pp.35-39.

[6] W. Hotzgruber. New ESR Technology for New Improved Products. Proceeding of 7th International Conference on Vacuum Metallurgy, Tokyo Japan, (1982), pp.1452-1458.

[7] Y. X. Lu, D. H. Hu. Electro-hydarulic Proportional Control Technology. Beijing: China Machine Press (1998).

[8] J. C. Song, Y. Wang, et al. Study on the Electro-Hydraulic Proportional Controlled Aircraft Arresting System, Acta Aeronauticaet Astronautica Sinica, Vol. 26(4) (2005), pp.520-523.

[9] S. J. Julier, J. K. Uhlmann. Unscented filtering and nonlinear estimation, IEEE Proc of Aerospace and Electronic Systems. Vol. 92(3) (2004), pp.401-422.

DOI: 10.1109/jproc.2003.823141
