Microstructure Evolution of Sn-3.5Ag-1.0Cu-0.5Ni/Cu System Lead Free Solder under Long Term Thermal Aging

Abstract:

Due to environmental concerns, lead-free solders were introduced in replacing the lead-based solders in microelectronics devices technology. Although there are many lead-free solder available, the Sn-Ag-Cu solder was considered the best choice. But the solder has its draw backs in terms of melting temperature and intermetallic formations. In this study, the effect of 0.5wt% Ni addition on the microstructure of the Sn-3.5Ag-1.0Cu solder was investigated. The solder was synthesized via powder metallurgy route which includes blending, compacting and sintering. The solders were characterized for its densities and melting temperatures. SEM was used to observe the microstructure of intermetallic phases. The solders were melted on copper substrate at 250°C for one minute and aged at 150°C from 0 to 400 hours. The phases formed were studied under SEM. The SEM results showed the presence of Cu₆Sn₅, Cu₃Sn, Ag₃Sn and (Cu,Ni)₆Sn₅ intermetallics.

• Periodical: Advanced Materials Research (Volume 620)
• Pages: 263-267
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.620.263
• Online since: December 2012
• Authors: Noor Asikin Ab Ghani, Iziana Yahya, Mohd Arif Anuar Mohd Salleh, Saidatulakmar Shamsuddin, Zainal Arifin Ahmad, Ramani Mayappan
• Keywords: Intermetallic, Powder metallurgy, Scanning Electron Microscope (SEM), Sn-Ag-Cu-Ni, Thermal Aging

References

[1] R. Mayappan and Z. A Ahmad: Sains Malaysiana Vol. 38 (2009), pp.395-400.

[2] W.C. Luo, C.E. Ho, J.Y. Tsai, Y.L. Lin and C.R. Kao: Material Science and Engineering. Vol. 396 (2005), pp.385-391.

[3] J.W. Yoon, B.I. Noh, B.K. Kim, C. C Shur and S.B. Jung: Journals of Alloys and Compounds. Vol. 486 (2009), pp.142-147.

[4] M.E. Alam, S.M.L. Nai and M. Gupta: Journals of Alloys And Compounds Vol. 476 (2009), pp.199-206.

[5] C.F. Tseng, T.K. Lee, G. Ramakrishna, K.C. Liu and J.G. Duh: Materials Letters. Vol. 65 (2011), pp.3216-3218.

[6] H. Watanabe, M. Shimoda, N. Hidaka and I. Shohji: Key Engineering Materials. Vol. 462-463 (2011), pp.247-252.

DOI: 10.4028/www.scientific.net/kem.462-463.247

[7] L. Wang, F. Sun, Y. Liu, and L. Wang: International Conference f Electronic Packaging Technology and High Density Packaging. (2009) 978-1-4244-4659.

[8] J. Wei, S. M. L. Nai, C. K. Wong and M. Gupta: SIMTech technical reports Vol. 6, 1 (2005), pp.29-32.

[9] K.S. Kim, K. Suganuma, T. Shimozaki and C.G. Lee. Material Science Forum Vol. 439 (2003), pp.7-11.
