Electrical Discharge Machining (EDM): Selection of Dielectric in Machining ASSAB 718HH

Abstract:

Electrical Discharge Machining (EDM) in Malaysia is widely used in mould making industries. Parts for automotive, defence and telecommunication industries are also other examples of the products produced. The process is based on removing material from a part by a series of repeated electrical discharges between a tool called electrode and the work piece with the presence of dielectric. The dielectric serves as transportation of removed particles, remains electrically non-conducting until the breakdown voltage is reached, reconditions the dielectric strength, increases the energy density in plasma channel and cools the electrode. This paper presents the machining of ASSAB 718HH work pieces with copper tool using EDM die sinking method. Three commercial EDM dielectrics; Kerosene, Novis and Amoil were tested and comparison between material removal rate (MRR), tool wear ratio (TWR) and surface finish (SF) are given. Through Pugh Method, result shows that ASSAB 718HH is best machined with Novis.

• Periodical: Advanced Materials Research (Volumes 622-623)
• Pages: 520-524
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.622-623.520
• Online since: December 2012
• Authors: Norliana Mohd Abbas, Darius Gnanaraj Solomon
• Keywords: ASSAB 718HH, Dielectric, Electrical Discharge Machining (EDM), Material Removal Rate (MRR), Surface Finish, Tool Wear Rate

References

[1] E.J.A. Armarego, R.H. Brown, The Machining of Metal. New Jersey: Prentice Hall Inc. (1969).

[2] Darius G.S., Berhan M.N., Adam H., Akramin M.Z., The Use Of Pugh Method In The Selection Of The Best Friction Material, 4th Malaysian Friction Materials Colloquium (2006).

[3] Darius G.S., Berhan M.N., David N.V., Shahrul A.A. and Zaki B., Selection of the Best Friction Material Formulation Based on the Physical and Mechanical Properties, Brake Friction Materials, Edited by Darius G. Solomon, UPENA, UiTM, Malaysia, (2006).

[4] http: /www. assab-china. com/ASPAC_718HH_080718_Ed. pdf [Downloaded on 20 Mac 2010].

[5] Shankar Singh, S. Maheshwari, P.C. Pandey, Some Investigations Into the Electric Discharge Machining of Hardened Tool Steel using Different Electrode Materials, Journal of Materials Processing Technology, (2004). vol. 149, p.272–277.

DOI: 10.1016/j.jmatprotec.2003.11.046

[6] J.A. McGeough, Advanced Methods of Machining. London: Chapman and Hall, (1998).

[7] Li Li, Y. S. Wong, J.Y.H. Fuh, L. Lu, EDM performance of TiC copper-based sintered electrodes, Materials and Design, (2001) vol. 22, pp.669-678.

DOI: 10.1016/s0261-3069(01)00010-3

[8] P. Pecas and E. Henriques, Influence of Silicon Powder-Mixed Dielectric on Conventional Electrical Discharge Machining, International Journal of Machine Tools & Manufacture, (2003), vol. 43, p.1465–1471.

DOI: 10.1016/s0890-6955(03)00169-x

[9] Dielectric fluid [<http: /www. unl. edu/nmrc/Diesinking/surfaceint/surface. htm> 18 Dec 2005].

[10] Spiros Zinelis, Surface and Elemental Alterations of Dental Alloys Induced by Electro Discharge Machining (EDM), Dental Materials, doi: 10. 1016/j. dental. 2006. 03. 021.

DOI: 10.1016/j.dental.2006.03.021
