Kinematic Analysis and Simulation of an A/C Axes Bi-Rotary Milling Head with Zero Transmission

Abstract:

Because of the flexible kinematic characteristic of five-axis-linkage machining center it is widely used to process complex parts. The milling head is the key functional component of the five-axis machining center, therefore study of the milling head is of vital importance. The A/C axes bi-rotary milling head is the most common used structures. The current mechanical A/C axes bi-rotary milling head is mostly with large volume and small rotation range. This paper presents an A/C axes bi-rotary milling head with zero transmission in small volume. To understand the kinetic characteristics of the A/C axes bi-rotary milling head with zero transmission, we apply D-H parameter method to establish displacement equations, speed equations, and acceleration equations. SolidWorks is then utilized to build the virtual prototyping model of the designed mechanism. Motion module of SolidWorks is also used to carry out the kinematics simulation. The experimental results show that the mechanism could achieve the rotation of A/C axes and smooth motion trajectory. The rotation range of A-axis could reach ±120°.

• Periodical: Advanced Materials Research (Volume 625)
• Pages: 146-150
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.625.146
• Online since: December 2012
• Authors: Yong Chen, Mei Fa Huang, Bo Shi, Meng Meng Xiao, Ru Kai Hu, Jiang Sheng Tang
• Keywords: Bi-Rotary Milling Head, Kinematics Analysis, Simulation, SolidWorks, Zero Transmission

References

[1] Lin Jianfeng, Yan Ming, Zheng Peng, etc. Modal analysis of the direct driving type A/C axes bi-rotary milling head [J]. Mechanical transmission, 2010, 34(5): 59-63.

[2] Muditha Dassanayake, Tsutsumi Masaom, SaitoAkinori. A strategy for identifying static deviations in universal spindle head type multi-axis machining centers [J]. International Journal of Machine Tools & Manufacture, 2006, 46: 1097—1106.

DOI: 10.1016/j.ijmachtools.2005.08.010

[3] Zhang Zhengpo, Qin Xuedong. Analysis and design discussion of five-axis-linkage machine structure performance [J]. Equipment Manufacturing Technology, 2009, 21(10): 5-8.

[4] Foo C, Rahman M F. Direct Torque Control of an IPM —Synchronous Motor Drive at Very Low Speed Using a Sliding Mode Stator Flux Observer [J]. IEEE Transactions on Power Electronics, 2010, 25 (4): 933-942.

DOI: 10.1109/tpel.2009.2036354

[5] Legge D. Tube end milling head: US2010074699 [P].

[6] Ma Shenming. Structure characteristics analysis and simulation research of big power and torque angular milling head [D]. Beijing: Beijing University of Technology, (2008).

[7] Sun Huan, Chen Zuomo, Ge Wenjie. Principle of machinery [M]. Beijing: Higher Education Press, 2006: 13-14.

[8] Sun Lining, Ding Qingyong, Liu Xinyu. The kinematics optimization design of high speed and high precision parallel robot of 2 degrees of freedom [J]. Chinese Journal of Mechanical Engineering, 2005, 41(7): 94-98.

DOI: 10.1109/iros.2005.1544970

[9] Xiong Qijia, Wu Hongtao, Wang Chaoqun, etc. Kinematic analysis of 2 DOF parallel mechanism [J]. Mechanical Science and Technology, 2005, 41(7): 94-98.

[10] Wang Fang, Zhang Haiyan. The kinematics simulation of the linkrod based on simulink [J]. Machine Design Research, 2004, 20(2): 35-37.

[11] Han Jianhai. Industrial robots [M]. Wuhan: Huazhong University of Science and Technology Press, 2009: 61-65.
