Graphic Method for Design of Eccentric Slider-Crank Mechanism and Analyzing of Feasible Region

Abstract:

Based on the analysis to the geometric relations of eccentric slider-crank mechanism (ESCM) at two limiting positions, a new and simple graphic method for design of ESCM was proposed in the paper. The method has the characteristics of legible concept, concise operation and good practicality. Utilizing the new method, the ESCM could be designed quickly under given conditions (slider stroke H, coefficient of travel speed variation K, the auxiliary conditions such as the length of crank a, length of connecting rod b and deflection distance e) without any calculation. Meanwhile, under given conditions (H, K) the alternative region of crank fixed center A, the possible feasible regions of crank length a and deflection distance e were discussed.

You might also be interested in these eBooks

Research on Mechanics, Dynamic Systems and Material Engineering

View Preview

Info:

Periodical:

Advanced Materials Research (Volume 625)

Pages:

88-92

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.625.88

Citation:

Cite this paper

Online since:

December 2012

Authors:

Cai Zhe Hao, Shi Hui Ma, Guang Xin Cai, Jian Guo Yu, Zhi Ning Jia

Keywords:

Eccentric Slider-Crank Mechanism, Feasible Region, Geometric Relation, Graphic Method
