Computer Aided Design Based on Visual FORTRAN and AutoCAD

Abstract:

Aimed at disadvantages of tedious work of the gear teeth design, Visual Fortran is taken as the development platform, and design data are stored and managed by self-developed program and database technology. A CAD System for Gear Teeth named GTCS is researched and developed. The system integrates designing and drawing in a body, and fully uses the powerful numerical calculation function of Visual Fortran and the function of Windows interface design, as well as the secondary development function of AutoCAD and database technology, etc. The software can realize designing and calculating of involute gear teeth and transmission mechanism, automatic drawing and various kinds of results post-processing. Results show that the research results greatly improved the efficiency and quality of the design. The result documents are easily accessible by other structural analysis software (such as SolidWorks, ANSYS, ADINA, etc) and similar design software, and convenient to use for the follow-up work.

• Periodical: Advanced Materials Research (Volume 628)
• Pages: 245-248
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.628.245
• Online since: December 2012
• Authors: Yu He Li, Peng Xu, Xin Li Bai
• Keywords: Autolisp, Automatic Design, Computer Aided Design (CAD), Interface, Visual Fortran

References

[1] G.R. Liu, X.L. Bai: Water conservancy and hydropower technology Vol. 35 (2004), p.35.

[2] S.P. Liu: Mechanical design and manufacturing Vol. 28 (2005), p.77.

[3] W.B. Wang: Machinery 30 (2003): 65-66.

[4] X. Lu: Agriculture equipment and vehicle engineering, Vol. 31 (2007), p.26.

[5] S.Q. Ge: Coal mine machinery, Vol. 29 (2008) p.202.

[6] H.Z. Yao: AutoCAD2004 interaction engineering drawing and secondary development, (Mechanical Industry Press, Beijing, 2004).

[7] X.J. Cao: Mechanical transmission, Vol. 31 (2007), p.65.

[8] X.F. Zhang, et al: Design and research, Vol. 26 (2008), p.1.

[9] L.T. Wang: Mechanical CAD/CAM technology (Mechanical Industry Press, Beijing, 2001).

[10] L.R. Xiang, et al: Engineering design CAD and intelligent building, Vol. 19 (2002), p.72.
