Research on Box Drawing Coefficient of Friction Based on Dynaform

Abstract:

The box body drawing process is prone to breakage defect. Using finite element analysis software Dynaform5.7, the box part in deep drawing process was simulated. The friction coefficient was observed to change between sheet metal and die. Analysis of sheet metal forming limit and wall thickness distribution，therefore came out with the following conclusion：box deep drawing is affected by the lubrication , when the friction coefficient is lower than 0.17, Lubrication can effectively prevent the box shaped parts from cracks. At the same time, the research still is developing a new drawing.

• Periodical: Advanced Materials Research (Volume 628)
• Pages: 223-228
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.628.223
• Online since: December 2012
• Authors: Zhi Gao Luo, Xu Dong Li, Jing Jing Zhang, Jun Li Zhao
• Keywords: Box Shaped Parts, Forming Limit, Friction Coefficient (FC), Thickness Variation

References

[1] Chen chuansheng chen, the deformation of the analytical stress at the corner of box deep drawing［J］. Mechanical and electrical engineering, 2007, 24( 3) : 61-63.

[2] zhang Zhang yu, ，zhang xu，an guozhi. Based on the numerical simulation of automobile covering mould reverse design [J]. Tool technology 2009, 43( 7) : 53-55.

[3] liu Liu linqiang，, tian Tian fuxiang. the The selection of lubricant and lubrication in the deep drawing process [J]. Mould manufacturing，, 2004, 3( 7) : 72-74.

[4] Farrahshaida Mohd Salleh，, Izdihar Tharazi，, Abdul Rahman Omar, et al Minimizing the Drawing Stages of a Bracket Assembly Upper Spring Using DYNAFORM[C] IEEE Colloquium on Humanities, Science and Engineering Research, Dec. 2011 : 5-6.

DOI: 10.1109/chuser.2011.6163751

[5] wang Wang xiufen，, CAE design and application of the sheet metal forming: based on DYNAFORM [M]. beijing: Beijing aerospace university press, 2008.

[6] qiu Qiu hongyang，, huang yajuan，influence Influence from friction in sheet metal stamping performance [J]. Mould industry: 2005( 1) : 14 -17.

[7] wang Wang yun，, yu jin，the The finite element analysis and mold design in sheet metal drawing [J]. Micro &special motor: 2009( 7) : 62 -64.

[8] wang Wang yinzhi, box Box deep drawing form of the numerical simulation and analysis based on the Dynaform［J］, ］. Machine and hydraulic, 2011, 39(1 3) : 114-117.
