Design and Performance Analysis Based on High-Speed Switching Valve of Magnetorheological Plug-Mounted

Abstract:

Based on the rheological mechanism of magnetorheological fluid，we can design a kind of magnetorheological high-speed on-off valves,which used the Plug-in structure.It is shows that， through the static and dynamic performance analysis of the valves，the magnetorheological high-speed on-off valves not only has the good static, dynamic characteristics, compare to magnetorheological plug-mounted speed switch valve with traditional hydraulic, and with high speed of response, high stability, etc . It is an easy to achieve automatic control and intelligent control of the hydraulic components.

• Periodical: Advanced Materials Research (Volume 630)
• Pages: 106-109
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.630.106
• Online since: December 2012
• Authors: Yun Han Liu, Zhang Yong Wu, Xian Wang, Zhen Hua Duan, Xiao Yan Gao, Jin Tao Qu
• Keywords: Cartridge Type Switch Valve, MRF, Performance Analysis

References

[1] Kordonsky W I. Magnetorheological effect as a base of new devices and technologies[J]. Magnetism and Magnetic Materials, 1993, 122(1-3): 395-398.

DOI: 10.1016/0304-8853(93)91117-p

[2] ZHANG lin, LI yanxi. Designing a control system of a new type magnetorheological valve. [J]. Chinese Hydraulics $ Pneumatics, 2006（9）：28-29.

[3] AI hongxia. Reseach of magnetorheological valve and with damping characteristics of magnetorheological hydraulic actuators. [ Master's degree thesis]. Chongqing, Chongqing university, (2005).

[4] Chenggang, et al. Reseach the properties of magnetorheological fluid control valves. [J] journal of Wuhan university of science and technology, 2005(3)27-29.

[5] . ZHANGsihai et al. Reseach the flow control of magnetorheological valve of pulse modulation (PWM) control [J]. Chinese Hydraulics $ Pneumatics, 2005(1)57-58.

[6] WANGjingtao et al. Application prospect of the magnetic fluid technology in Hydraulic transmission and control. [J]Machine Tool &Hydraulics, 2011(10)131-132.

[7] JIANGjihai. Hydraulic transmission. Haerbin: Harbin institute of technology press. (2007).

[8] CENGshunfeng. Researching digital variable pump based on the high speed switch valve. [ Master's degree thesis]. Kunming, Kungming university of science and technology. (2011).
