Polarization Properties of Polymer Photonic Crystal Fiber with Square-Lattice Elliptical Air-Hole

Abstract:

A novel type of photonic crystal fiber for high birefringence and zero-walkoff is proposed based on polymer, the fiber is composed of a solid polymer core and a cladding with square lattice elliptical air-holes along the fiber length. The optical birefringence and polarization-dependent leakage loss are studied numerically based on the full-vector finite element method(FEM). Numerical results show that the proposed fiber has heightened modal birefringence of the order of 10^-2; and the leakage loss is reduced to 0.08dB/m at wavelength of 0.65μm when it has 10 rings of elliptical air-holes. So the proposed PCFs may be useful in the field of high birefringence polarization-maintaining optical communication.

• Periodical: Advanced Materials Research (Volumes 631-632)
• Pages: 233-238
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.631-632.233
• Online since: January 2013
• Authors: Fei Liu, Hong Yan Gao, Yu Qian
• Keywords: Guided-Wave Optics, High Birefringence, Leakage Loss, Photonic Crystal Fiber (PCF), Polarization Properties

References

[1] KNIGHT J C, BIRKS T A, RUSSEL P S J, et al. All-silica single-mode optical fiber with photonic crystal cladding[J]. Opt Lett, 1996, 21(19): 1547-1549.

DOI: 10.1364/ol.21.001547

[2] ZHANG Ya-ni, MIAO Run-cai. Optimized design of photonic crystal polarization maintaining fibers with elliptical core[J]. Journal of Optoelectronics × Laser, 2006, 17(5): 529-532.

[3] ZHANG Ya-ni. Study on polarization error in depolarized fiber optical gyroscope[J]. Journal of Optoelectronics × Laser, 2007, 18(7): 792-795.

[4] J. Noda, K. Okamoto, Y. Sasaki. Polarization-maintaining fibers and their applications[J]. J. Lightwave Technol., 1986, LT-4(8): 1071-1086.

DOI: 10.1109/jlt.1986.1074847

[5] ZHANG Ya-ni. Polarization Properties of Rectangular Lattice Microstructured Polymer optical Fiber[J]. Acta Photonic Sinica, 2009, 38 (1): 34-38.

[6] ZHANG Ya-ni, MIAO Run-cai, Ren Li-yong, et al. High birefringence polymer photonic crystal fiber with elliptical core non-hexangular symmetry[J]. Acta Photonic Sinica, 2007, 36(6): 749-754.

DOI: 10.1088/1009-1963/16/6/039

[7] ZHANG Ya-ni, MIAO Run-cai, Ren Li-yong, et al. Polarization properties of elliptical core non hexagonal symmetry polymer photonic crystal fiber[J]. Chinese Physics, 2007, 16(6): 5541- 5547.

DOI: 10.1088/1009-1963/16/6/039

[8] BIRKS T A, KNIGHT J C, RUSSEL P S J. Endlessly single-mode photonic crystal fiber[J]. Opt Lett., 1997, 22(13): 961-963.

DOI: 10.1364/ol.22.000961

[9] CREGAN R F, MANGAN B J, KNIGHT J C, et al. Single-mode photonic band gap guidance of light in air[J]. Science, 1999, 285(3): 1537-1539.

DOI: 10.1126/science.285.5433.1537

[10] LOU Shu-qin, WANG Zhi, REN Guo-bin, et al. Polarization properties of elliptical core photonic crystal fiber[J]. Journal of Optoelectronics ·Laser, 2004 , 15 (9) : 1021-1025.

[11] M. J. Steel, R. M. Osgood, Jr. Polarization and dispersive properties of elliptical-hole photonic crystal fibers[J]. J. Lightwave Technol., 2001, 19(4): 495-503.

DOI: 10.1109/50.920847

[12] GUO S P, SACHARIA A. Simple plane wave implementation for photonic crystal calculations[J]. Opt Express, 2003, 11 (2): 167-175.

DOI: 10.1364/oe.11.000167

[13] LEUNG K, LIU Y. Full vector wave calculation of photonic band structure in face-centered-cubic dielectric media[J]. Phys Rev Lett, 1990, 65(11): 2646-2649.

DOI: 10.1103/physrevlett.65.2646
