Effect of Heat Treatment to Twin-Wire Arc Spraying Ni-5wt.%Al Coating on 6061-T6 Aluminum Alloy Diffusion

Abstract:

In this study, Ni-5wt.%Al coating was fabricated on the 6061-T6 aluminum alloy substrate by twin-wire arc spraying technology. Through different heat treatment process, effect of microstructure and phase structure was studied with different temperature and time. Interface reaction mechanism of alloy coating/substrate and diffusion behavior of elements was discussed. Heat treatment was carried out at 400°C，480°C，550°C and respective for 4h, 24h, 48h. The XRD , SEM and EDS results showed that main phases of Ni-5wt.%Al original coating were composed of Ni solid solution, in addition to a small amount of Al₂O₃, NiO and Al₄Ni₃. Phase composition has basically not changed, interface of the coating/substrate occurred diffusion, which was controlled by the diffusion of Al atoms. Intermetallic compounds of NiAl3 and Ni₂Al₃ were formed in interface of coating/substrate, and interface diffusion area gradually was thickened.

You might also be interested in these eBooks

Materials Engineering for Advanced Technologies (ICMEAT 2012)

View Preview

Info:

Periodical:

Advanced Materials Research (Volumes 631-632)

Pages:

424-428

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.631-632.424

Citation:

Cite this paper

Online since:

January 2013

Authors:

J.X. Wang, J.F. Sun, Z.P. Wang

Keywords:

Coating, Diffusion, Ni-5wt.%Al

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] V Vega, U Nguyen Huynh, J Holmes, et al. Analysis of Heat Effects on Marine Corps AM2 Mat Mechanical Properties. Journal of Materials Engineering and Performance, 2011, 20(2): 257-264.

DOI: 10.1007/s11665-010-9669-2

Google Scholar

[2] Liu Shen-zhong, Gong Xiao-hui. STUDY OF PLASMA SPRAYING NICKEL COATING ON ALUMINIUM ALLOY. Acta Materiae Compositae Sinica, 1999, 16(1): 30-34.

Google Scholar

[3] QI Jing, SONG Yu-qiang, LI Shi-chun. Experimental analysis on solid-state diffusion of Al/Fe/Ni interface. Journal of China University of Petroleum, 2008, 32(4): 91-94.

Google Scholar

[4] LEI Junpeng, DONG Xinglong, ZHAO Fuguo, et al. PREDICTION OF THE PRIMARY INTERMETALLIC COMPOUND NANOPARTICLES FORMED IN Fe(Ni)-Sn SYSTEM. Acta Metallurgica Sinica, 2008, 44(8): 922-926.

Google Scholar

[5] LIU Chang-ying, WANG Zhi-qi, TAO Xiao-ke. Inlay Electroplating Technology and Properties of Ni-Al2O3 Coating. Journal of Materials Protection, 2003, 36(2): 33-35.

Google Scholar
