The Wind-Induced Response of High-Pier Long-Span Continuous Rigid Frame Bridge

Abstract:

The fluctuating wind field is simulated for digital by using the AR method. A three-dimension finite element model of high-pier long-span rigid frame bridge is presented in this paper. Based on this model, the gust-induced static response of the bridge under the longest cantilevered construction stage is computed. By comparing with those of two similar span rigid frame bridges with low piers, the gust-induced response characteristics of the internal force under the bottom of the piers of the high-pier long-span bridges are investigated, which is helpful for the safe design of bridges. The buffeting responses of the bridge under the longest cantilevered construction stage are also calculated in the time domain, taking account of the longitudinal and vertical turbulence action. Through the spectral analysis of the response, the comfort index of Diekemann is obtained. The effects of buffeting response on the workers’ safety under the most unfavorable construction stage are discussed.

• Periodical: Advanced Materials Research (Volumes 639-640)
• Pages: 502-509
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.639-640.502
• Online since: January 2013
• Authors: Jia Wen Zhang
• Keywords: Bridge Engineering, Continuous Rigid Frame Bridge, Safety Index, Spectral Analysis, Time Domain Analysis, Wind Induced Response

References

[1] L.S.BAO, K.T.LIU, L.YU, H. NIU, Numerical Simulation of Spatial Fluctuating Wind Field on Long Span Bridges, Journal of Shenyang Jianzhu University. 26 (2010) 238-243.

DOI: 10.1061/47625(404)15

[2] B.L. Ma, High-pier long-span continuous rigid frame bridges. China Communications Press, Beijing, 2001.

[3] R.H. Scanlan, Bridge buffeting by skew winds in erection stages. Journal of Engineering Mechanics. 119 (1993) 251-269.

DOI: 10.1061/(asce)0733-9399(1993)119:2(251)

[4] P.A. Mendes, F.A. Branco, Unbalanced wind buffeting effects on bridges during double cantilever erection stages. Journal of Wind and Structures. 4 (2004) 45-62.

DOI: 10.12989/was.2001.4.1.045

[5] S.Schmidt, G.Solari, 3-D wind-induced effects on bridges during balanced cantilever erection stages. Wind and Structures, An International Journal, 6 (2003) 1-22.

DOI: 10.12989/was.2003.6.1.001

[6] A.R. Chen, H.F. Xiang, Aeroelasticity of long-span rigid frame bridges under construction stage. Journal of Vibration Engineering. 12 (1999) 535-539.

[7] A.R. Chen, H.F. Xiang, Method for wind load computation under the cantilever constructions stage. Highway. 3 (1998) 7-10 .

[8] J.J. Wang, J.Li, Evaluation of vehicle-bridge vibration effect on the passengers. Railway Architecture. 7 (2003) 6-8.

[9] Ministry of Communications of the People's Republic of China. Wind-resistant design specifications for highway bridges. JTG/T D60-01-2004. 2004 .

[10] Y.H. Cao, Nonlinear flutter and buffeting analysis of long-span bridges. Ph D Thesis. Tongji University, Shanghai ,1999.

[11] W.Z. Wang, G.L. Liu, J.Y.Gu, The control of wind induced vibration at the cantilever construction stage of Assistant Shipping Channel Bridge of Humen Bridge. Bridge Construction. 5 (2002) 50-53.
