Time Effect of the Pile Bearing Capacity in Dredger Fill

Abstract:

The dissipating of pore water pressure caused by pile sinking is one of the main factors resulting in time effect of ultimate bearing capacity of pile.The pore water pressure is monitored at each observing point during pile sinking and after that. With the pore pressure plan embedded in advance, by means of spot test in the process of pile sinking, under this geological conditions of the pile foundation by referring to the second phase project of the free port logistics processing zone in Dongjiang, Tianjin.The change law of the distribution and dissipation of excess pore water pressure with time, depth, radial distance and permeability coefficient of soil was also discussed. It’s found that the excess pore water pressure attenuates approximately linearly with the increase of the distance from the pile heart and the scope influenced is around 10d. As the numerical simulation accord with the test results effectively, promote the results then get the change rule of pile bearing capacity with time.The formula of pile bearing capacity about time effect in dredge fill was deduced for engineering reference.The effect of soil internal friction angle on the ultimate bearing capacity of pile was discussed. Numerical simulation shows that the ultimate bearing capacity of pipe pile increases over time and keeps stable after 20d.The ultimate limit bearing capacity is 1473kN with increase of 12.3%, the time when it reaches the stable state is in accord with the excess pore water pressure dissipation monitored at each observing point. The larger the internal frictional angle of soil becomes, the more the ultimate bearing capacity is. The angle exceeding 20°,the bearing capacity would not increase as internal frictional angle of soil increases.

• Periodical: Advanced Materials Research (Volumes 639-640)
• Pages: 630-638
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.639-640.630
• Online since: January 2013
• Authors: Hua Yang Lei, Qian Qian Lv
• Keywords: Bearing Capacity, Dredge Fill, Excess Pore Water Pressure, Pipe Pile, Time-Effect

References

[1] H.F. Feng, Reinforcement method of ultra soft foundation formed by fresh dredger filled mud, Port Engineering Technology. 48 (2011) 59-60.

[2] T.J. Wang, On strengthening plan selection of cast-in-situ box girder subgrade in dredger fill soil layer with large-thickness, China Municipal Engineering. 4 (2011) 46-49.

[3] R.J. Jardine, J.R. Standing, F.C. Chow, Some observations of the effects of time on the capacity of piles driven in sand. Geotechnique. 56 (2006) 227-244.

DOI: 10.1680/geot.2006.56.4.227

[4] J.H. Long, J.A. Kerrigan, M. H. Wysockey, Measured Time Effects for Axial Capacity of Driven Piling, Transportation Research Record: Journal of the Transportation Research Board. 1663(1999) 8-15.

DOI: 10.3141/1663-02

[5] M.Y. Zhang, J.W. Liu, X.X. Yu, Field test study of time effect on ultimate bearing capacity of jacked pile in soft clay, Rock and Soil Mechanics. 30 (2009) 3005-3009.

[6] S.D. Tang, L.S. He, Z. Bo, Excess pore water pressure caused by an installing pile in soft foundation, Rock and Soil Mechanics. 23(2002) 725-729.

[7] M.Y. Zhang, W. Shi, C.G. Wang, Time effect on the ultimate bearing capacity of static pressed pile, Chinese Journal of Rock Mechanics and Engineering. 21 (2002) 2601-2604．

[8] F.C. Chow, R.J. Jardine, J.F. Nauroy, Time-related increase in shaft capacities of driven piles in sand, Geotechnique. 47 (1997) 353-361.

DOI: 10.1680/geot.1997.47.2.353

[9] P. Doherty, K. Gavin, The shaft capacity of displacement piles in clay: a state of the art review, Geotech. Geol. Eng. 29 (2009) 389–410.

DOI: 10.1007/s10706-010-9389-2

[10] F. Bruey, K. Meunier, J.F. Neuroy, Behaviour of pile plug in sandy soils during and after driving, 23rd Offshore Technology Conference, Houston, 1991:145-154．

[11] W.K. Ng, M.R. Selamat, K.K. Choong, Soil/Pile Set-up Effects on Driven Pile in Malaysian Soil, EJGE. 14 (2010) 1-12.

[12] Z.X. Hu, Growth of pile bearing capacity in saturated soft clay over time, Chinese journal of Geotechnical Engineering. 7 (1985) 58-61．

[13] K. Fei, J.W. Zhang, The Application of ABAQUS in Geotechnical Engineering, first ed., China water conservancy and hydropower press, Beijing, 2010.

[14] Pile foundation engineering manuals committee. Pile foundation Engineering Manual, first ed., China architecture &building press, Beijing, 1998.

[15] J.L. Hu, D.Q. Wen, Calculation method and effect factors analysis on bearing capacity of prestressed pipe pile, Yellow River. 29 (2007) 51-52.
