Effect of the Metal Block on the Stress Distributed in the Adhesively Bonded Single Lap Steel Joint

Abstract:

The effect of 4 mm long metal block bonded to the end of the overlap zone on the stress distributed in adhesively bonded single lap steel joint was investigated using elasto-plastic finite element method (FEM). The results from the numerical simulation showed that the stress is varied a little when the joints with a couple of 4 mm long metal block adhered to both ends of the over lap or with a couple of adhesive fillet. Compared to the joint without the metal block, it is advantageous of reducing the peak stress in the adhesive layer near the ends of the lap zone in adhesively bonded single lap steel joints but its effect is less than that of the joint with a couple of adhesive fillet. There is no evidential difference in the effects between the steel and aluminum block.

You might also be interested in these eBooks

Advanced Research on Intelligent Systems and Mechanical Engineering

View Preview

Info:

Periodical:

Advanced Materials Research (Volume 644)

Pages:

243-246

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.644.243

Citation:

Cite this paper

Online since:

January 2013

Authors:

Min You, Lai Hu Song, Jiang Cheng Zhang, Mei Li

Keywords:

Adhesives, Finite Element Analysis (FEA), Metal Block, Single Lap Joint, Steel, Stress Distribution

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] R. D. Adams, J. Comyn and W. C. Wake: Structural adhesive joints in engineering (Chapman & Hall, UK 1997).

Google Scholar

[2] Q Zeng, C T Sun: Collection of Technical Papers- AIAA/ASME/ASCE/AHS/ASC Structures, Structural Dynamics and Materials Conference, 2000, 1(II): 995-1003.

DOI: 10.2514/msdm09

Google Scholar

[3] G. Fessel, J. G. Broughton, N.A. Fellows, et al: Int J of Adhes. & Adhesives, Vol. 27(2007), p.574.

Google Scholar

[4] M. You, Y. Zheng, X. L. Zheng, et al: Int J of Adhesion and Adhesives. Vol. 23 (2003), p.365.

Google Scholar

[5] M. You, Y. Zheng, X. L. Zheng, et al: Key Eng. Mater. Vol. 385-387 (2006), p.225.

Google Scholar

[6] X. L. Zheng, J. L. Yan, M. You, et al: Adv. Mater Research. Vol. 602-604 (2012), p.2092.

Google Scholar
