Waveform Acquisition and Playback System in Electrical Energy for Energy Saving Based on STM32 Design

Abstract:

The design of the use of meaning law semiconductor introduced 32 bit low power processor STM32, can effectively improve the data processing and transmitting velocity storag improving the stability of the system, and can reduce the power consumption, so as to achieve the purpose of saving energy. Also uses dual channel input, one channel is used for collecting the known frequency and amplitude of the waveform, the other channel is a collection of changes in the waveform, in practical application can be cut, thus solving the fixed waveform acquisition channels are relatively simple, and the variable waveforms that are relatively complex contradiction, make the system clean and stable.

• Periodical: Advanced Materials Research (Volume 648)
• Pages: 206-209
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.648.206
• Online since: January 2013
• Authors: Chun Xia Dong
• Keywords: Dual Channel Input, Low Power, Processor STM32

References

[1] Dexing Zhou, Peng Wang, Shouzheng Fan . Based on FPGA Digital Storage Oscilloscope [J]. China Civil Aviation College Periodical , 2004, (02).

[2] Ji Zhang , Yanling Wang ,. Base on MUS Equivalent Sampling Oscilloscope Design [J]. Application of Electronic Technique , 2003, (05).

[3] Yufeng Deng, Fenghong Xiang, Xuefei Zhang,. The Research on Implementations of a Virtual Digital Oscilloscope [J]. Modern electronic technology , 2006, (18).
