The Experimental Investigation of WEDM for Surface Roughness of Hardened Tool Steel: SKD 61

Abstract:

SKD 61 is tool steel that recommended using for hot working as mold and die. . In order to making mold and die, Wire Electrode Discharged Machining (WEDM) has been most operation. The objective of this research was to study factors, which were affected on surface roughness and optimal parameters in WEDM of hardened tool steel. Material used in the experiment was tool steel JIS SKD 61 that was hardening by heat treatment process. Taguchi’s experimental design was conducted on 5 factors and 3 levels that L27 of Taguchi standard orthogonal array was chosen for the design of experiments. Power setting, off time off, wire feeding, wire tension and wire offset were chosen as factor for evaluation surface roughness. The importance level of the machining parameters was determined by analysis of variance (ANOVA). The optimum factors combination was obtained by using the analysis of signal- to-noise (S/N) ratios. Finally, experimentation was carried out an optimal solution of machining parameters for quality of surface roughness in WEDM process.

• Periodical: Advanced Materials Research (Volume 650)
• Pages: 588-592
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.650.588
• Online since: January 2013
• Authors: Khanchai Kosit, Komson Jirapattarasilp
• Keywords: SKD 61, Surface Roughness (SR), Tool Steel, WEDM

References

[1] S. S. Mahapatra and A. Patnaik, Optimization of wire electrical discharge machining (WEDM) process parameters using Taguchi method, Int J Adv Manuf Technol Vol. 37 (2006).

DOI: 10.1007/s00170-006-0672-6

[2] A. Mohammadi, A.F. Tehrani, E. Emanian, and D. Karimi, A new approach to surface roughness and roundness improvement in wire electrical discharge turning based on statistical analyse. Int J Adv Manuf Technol Vol. 39 (2008), p.64–73.

DOI: 10.1007/s00170-007-1179-5

[3] G. Bartarya, and S.K. Choudhury, A Regression Model for Force and Surface Roughness Estimation during Hard Turning, Advanced Materials Research, Vol 299-300 (2011), p.1167.

DOI: 10.4028/www.scientific.net/amr.299-300.1167

[4] C.J. Tu, and X. Gu, Research on the Predicted Model of the Surface Roughness in Dry Turning Hardened Steel, Advanced Materials Research, Vol. 337 (2011), p.363.

DOI: 10.4028/www.scientific.net/amr.337.363

[5] K. Jirapattarasilp, S. Keawkeakul, and P. Pongpal, The study of influenced factors affecting to quality of High Chromium Cast Iron Cylindrical Grinding, The Proceeding of The 2nd Inter. Conf. on Mechanical and Electronics Eng. (ICMEE), Vol. 2 (2010).

DOI: 10.1109/icmee.2010.5558407
