The Design and Simulation of Circuit for Electromagnetic Force Assisted Line Heating Device

Abstract:

In the process of line heating, a pulsed electromagnetic force is added to steel plates as an approximately consecutive constrained force of certain frequency. It improves the condition of steel plates heated at high temperatures and the efficiency of steel deformation and be conducive to the control of process and the improvement for the accuracy of deformation. According to the actual needs of electromagnetic force assisted line heating process, the design ideas of circuit for the electromagnetic force assisted line heating device (EFALHD) and functions of the branch circuits are introduced. The distribution of the electromagnetic force and parameters’ influence rules are analyzed by building magnetic field and circuit coupling model in ANSYS. By adding thermal analysis on the electromagnetic field analysis, a new method of line heating finite element analysis is established to support the parameter determinations of EFALHD.

• Periodical: Advanced Materials Research (Volumes 652-654)
• Pages: 2010-2018
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.652-654.2010
• Online since: January 2013
• Authors: Ji Wang, Qiang Liu, Yu Jun Liu, Bing Shi, Ye Dong Bao, Li Jun Zhang
• Keywords: Design of Circuit, Electromagnetic Force Assisted, Finite Element Analysis (FEA), Line Heating, Simulation of Circuit

References

[1] Shin J G, Ryu C H, Lee J H, et al. User-friendly, Advanced Line Heating Automation For Accurate Plate Forming[J]. Journal of ship production. 2003, 19(1): 8-15.

DOI: 10.5957/jsp.2003.19.1.8

[2] Ji Wang, Yujun Liu, Zhuoshang Ji, et al. Automatic Line-Heating Process for Forming the Double-Curved Shell Plates[J]. Journal of Ship Production. 2009, 25(1): 7-13.

DOI: 10.5957/jsp.2009.25.1.7

[3] Shin J G, Ryu C H, Nam J H. A Comprehensive Line-Heating Algorithm for Automatic Formation of Curved Shell Plates[J]. Journal of ship production. 2004, 20(2): 69-78.

DOI: 10.5957/jsp.2004.20.2.69

[4] Shin J G, Lee J M, Nam J H. An Efficient Algorithm For Measurement And Comparison of Large-Scale Hull Pieces In The Line-Heating Process[J]. Journal of ship production. 2004, 20(1): 60-67.

DOI: 10.5957/jsp.2004.20.1.60

[5] Bae K Y, Yang Y S, Hyun C M, et al. Derivation of Simplified Formulas To Predict Deformations of Plate In Steel Forming Process With Induction Heating[J]. International Journal of Machine Tools and Manufacture. 2008, 48(15): 1646-1652.

DOI: 10.1016/j.ijmachtools.2008.07.007

[6] Bing Shi. Analysis of Circuit And Simulation of Electromagnetic Force Aid line Heating[D]. Dalian University of Technology, 2011. (In Chinese).

[7] Da Xu, Wei Xu, Wenli Xu, et al. Investigation And Application of Pulse Electromagnetic Force Generator For Trailing Control of Welding Stress[J]. Transactions of The China Welding Institution. 2008(1): 9-12. (In Chinese).

[8] Wei Xu. A New Method of Controlling Welding Hot Crack And Distortion Based On Electromagnetic Force During Welding[D]. Harbin Institute of Technology, 2008. (In Chinese).
