Surface Roughness Analysis of Metal Spun Parts

Abstract:

The paper brings the results of roughness analysis of formed part produced by CNC multi-pass conventional metal spinning. The influence of the spindle speed, workpiece geometry and planar anisotropy of the blank on the formed part roughness was studied. For experiment design, an orthogonal array L27(313) was used and ANOVA (Analysis of Variance) was carried out. Based on the results it is determined that the higher spindle speed leads to rough surface finish. The surface roughness measured in different areas of experimental samples (corner R10, conical area, cylindrical area) indicates that the worst surface finish is in the conical area. Roughness in different directions refer to the sheet rolling direction shows minimal differences.

You might also be interested in these eBooks

Advances in Materials and Materials Processing

View Preview

Info:

Periodical:

Advanced Materials Research (Volumes 652-654)

Pages:

2006-2009

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.652-654.2006

Citation:

Cite this paper

Online since:

January 2013

Authors:

Peter Šugár, Jana Šugárová, Ján Petrovič

Keywords:

ANOVA, Metal Spinning, Roughness, Taguchi Method

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] M. D. Chen, R. Q. Hsu, K. H. Fuh. Forecast of shear spinning force and surface roughness of spun cones by employing regression analysis. Int. J. of Machine Tools and Manufacture. Vol. 41 (2001), p.1721 – 1734.

DOI: 10.1016/s0890-6955(01)00039-6

Google Scholar

[2] F. Ma, H. Yang, M. Zhang: Plastic deformation behaviors and their application in power spinning process of conical parts with transverse inner rib. Journal of Materials Processing Technology. Vol. 210 (2010), p.180 – 189.

DOI: 10.1016/j.jmatprotec.2009.07.006

Google Scholar

[3] M. M. El-Khabeery, M. Fattouh, M. N. El-Sheikh. On the conventional simple spinning of cylindrical aluminium cups. International Journal of Machine Tool & Manufacture, Vol. 31 (1991), No. 2, p.203 – 219.

DOI: 10.1016/0890-6955(91)90005-n

Google Scholar

[4] L. Wang, H. et al. Effects of roller feed ratio on wrinkling failure in conventional spinning of a cylindrical cup. Proceedings of the Institution of Mechanical Engineers, Part B, Journal of Engineering Manufacture. Vol. 225 (2011).

DOI: 10.1177/0954405410396024

Google Scholar

[5] L. Wang. Analysis of Material Deformation and Wrinkling Failure in Conventional Metal Spinning Process. Durham theses. (2012) Durham University. Available at Durham E-Theses Online: http: /etheses. dur. ac. uk/3537/ [Accessed October 2012].

Google Scholar
