An Approach of Robotic Kinematics Parameters Calibration

Abstract:

Aiming at tedious of parameters identification in the process of robot calibration, this paper proposed a method to directly establish parameter error equations based on relative distance error by using the kinematics model in which the parameters error were considered, employing a laser interferometer to measure a 6R robot end-effector displacement distance along its Cartesian coordinates system axis direction, and respectively recorded the joint angle position data to the measured points, then taking all recorded data as basis for the robot kinematics parameter errors identifying equations and employing a hybrid genetic algorithm to solve the equations. The result shown that incomplete distance info can be used to identify kinematics parameters error in robot calibration process.

• Periodical: Advanced Materials Research (Volumes 655-657)
• Pages: 1023-1028
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.655-657.1023
• Online since: January 2013
• Authors: Yong Gui Zhang, Heng Zhang
• Keywords: Distance Error, Error Identification, Genetic Algorithm (GA), Robot Kinematics

References

[1] Xuecai Zhou; Qixian Zhang, in: Robot, 17(1)(1995), p.1 (In Chinese).

[2] Hegao Cai, Chaochun Zhang, Weiguo Wu. in: china mechanical engineering, 9(10)(1997), p.11(In Chinese).

[3] M．Abderramm, A. ＆Whittaker, in: Robotics and Computer Integrated Manufacturing. 16(2000), p.1.

[4] GQ rsel Aliei, Bijan Shirinzadeh, in: Mechanism and Machine Theory. (2005), p.879.

[5] Xiaolin Zhong, John M. Lewis, Francis L. N. -Nagy. in: Robotics and Autono -mous Systems. 18(1996), p.395.

[6] Ying Bal, Dali Wang, in: IEEE Tmnsaetions on systems, man, and cybernetics --part B: Cybernetics, 34(2)(2004), p.1155.

[7] Chunhe Gong, Jingxia Yuan, Jun Ni, in: International Journal of Machine Tools & Manufacture. 40(2000)，p.2119.

[8] Jianying Guo, Tiansheng Lu, Letian Wang, in: Journal of Shanghai Jiaotong University. 37(14)(2003), p.1670 (In Chinese).

[9] Yonggui Zhang, Yumei Huang, Feng Gao, in: Transactions of the Chinese Society for Agricultural Machinery. 39(9) (2008), p.153 (In Chinese).
