Three Dimensional Assembly Tolerance Analysis of Gear Drivetrain

Abstract:

Assembly accuracy has a crucial impact on the movement, load and fatigue of gear drivetrain. In this paper, a methodology on the accuracy prediction and control of complex drivetrain is presented. The proposed approach tries to simplify the assembly tolerance computation but grasping main assembly error factors in the assembly process of gear drivetrain. Jacobian -Torsor method is used in the analysis process, and results show a proper performance which indicates a potential opportunity for further deep and wide research on the 3D assembly analysis and simplification method.
