Thermal Characteristic Analysis on a High Precision Turning Center’s Headstock

Abstract:

The performances of the high precision turning center will be influenced by the thermal characteristics of the headstock seriously, and accurately predict thermal characteristics of the headstock are helpful to improve the design level. The headstock of a high precision turning center produced by some plant has been regarded as the research objects of the paper. First the steady temperature distribution and thermal deformation of the headstock were calculated based the finite element analysis models of the headstock. Then the temperature sensitive points of the headstock were obtained by using the grey incidence analysis method. Finally the thermal error compensation model was built by using multiple linear regression method. The study lays a foundation for the thermal error compensation of the headstock of the turning center.

• Periodical: Advanced Materials Research (Volumes 655-657)
• Pages: 305-309
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.655-657.305
• Online since: January 2013
• Authors: Yao Man Zhang, Ren Jun Gu, Jia Liang Han
• Keywords: Compensation Technology, Grey Incidence Analysis, Thermal Characteristic, Turning Center

References

[1] H.T. Zhao, J.G. Yang and J.H. Shen: International Journal of Machine Tools & Manufacture, Vol. 47 (2007), p.1003

[2] D.A. Krulewich: Mechantronics, Vol. 8 (1998), p.395

[3] M. Mitsuishi, S. Warisawa and R. Hanayama: CIRP Annals-Manufacturing Technology, Vol.5(2001) No.1, p.275–280.

[4] Ting-Yu Chen, Wei-Jiunn Wei and Jhy-Cherng Tsai. International Journal of Machine Tools & Manufacture, Vol.39(1999) No. 12, p. (1961)

[5] J. S. Chen, W.Y. Hsu: International Journal of Machine Tools & Manufacture, Vol. 43(2003) No. 11, p.1163

[6] J.H. Lee, S.H. Yang: International Journal of Machine Tools & Manufacture, Vol. 12(2002), p.147

[7] M.Mori, H. Mizuguchi, and M. Fujishima. Manufacturing Technology,Vol. 58(2009), p.331

[8] C.E. Honegger and A, Tulsian: International Journal of Machine Tools & Manufacture, Vol. 50(2010), p.386

[9] W.S. Yun, S.K. Kim, D.W. Choi: International Journal of Machine Tools & Manufacture, Vol.39(1999), p.1087

[10] J.K. Choi and D.G. Lee: International Journal of Machine Tools & Manufacture, Vol.38(1998), p.1017
