The Numerical Simulation of the Flow Field in the Underground Hydrocyclone

Abstract:

For preventing sand in underground oil, this paper structures a model of hydrocyclone with the inside cyclone and the outside one seriesing and describes how it works. By the TGrid procedures, the all of the hydrocyclone is meshed with the tetrahedral and the boundary conditions are determined. The methods of Three-dimensional numerical simulation in FLUENT are used to simulate the velocity field distribution, the pressure field distribution, the path lines of the separated medition characteristics of the separated medium and the phase distribution of the medium. The affect of the internal separated medition characteristics to the separated performance is analysed. Through the simulation, it is found that the spiral fin in the hydrocyclone can guide the fluid to produce a vortex flow to meet the purpose of separating the solid-liquid. There is no formation of the air column comparing with the conventional cyclone, so the internal flow field is more stable to conductive to the separation of the media. It provides a basis for the improvement of the cyclone.

• Periodical: Advanced Materials Research (Volumes 655-657)
• Pages: 470-475
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.655-657.470
• Online since: January 2013
• Authors: Jing Chang Wang, Fu Lai Guo, Meng Hua Wu
• Keywords: Fluent, Hydrocyclone, Numerical Simulation, Preventing Sand, Solid-Liquid Separation

References

[1] E. Brethey. A new type hydro cyclone [P]. US Patent: No. 453105, 1891.

[2] Feng Jin Zhang , Xiaoguang Liu, etc. CFD simulation of internal flow field of gas - liquid cyclone [ J ] . Chemical Machinery , 2005 ; 32 ( 6 ) : 358 -361.

[3] Yuanyuan Wen. the numerical simulation of the the mixer internal flow field based on FLUENT [J] , filtration and separation. , 2010, 20: 27 -28.

[4] Fujun Wang computational fluid dynamics analysis -CFD software principle and application [M ] Beijing: Tsinghua University Press , (2004).

[5] Xuping Lu . the new cyclone desander flow field simulation analysis and separation performance study based on FLUENT [ D ] , Chongqing University, (2010).

[6] XueShi Pang. Hydrocyclone theory and application [M ] . Changsha : Central South University Press , 2005, 6.

[7] Zhibin Wang, CHEN Wen-mei . the cyclone air column characteristics investigate [J]. Chemical Equipment Technology by numerical simulation , 2005, 26 ( 6 ) : 17.

[8] Xiaomin Liu , Minghu Jiang, Zunce Wang, characteristics research of cylindrical spiral flow field in dynamic hydrocyclone [J]. Of petroleum , 2003, 24 ( 2 ) : 89-93.

[9] Xiaomin Liu , Minghu Jiang. The stability analysis of air nuclear in Hydrocyclone [ J ] . Petroleum Technology , 2004, 25 ( 6) : 108 -109.

[10] Zhibin Wang , Zongwei Yang , Liangyin Chu, air nuclear processes in hydrocyclones [J]. Petroleum Machinery , 2009, 37 ( 12) : 5 -6.
