Research on Geometric Dimensioning Automatic Detection of Tubular Member

Abstract:

Geometric dimensioning measurement is a very important application in metrology. In this paper, we focus on the geometric dimensioning automatic detection of tubular member based on the laser displacement sensor. An automatic detection system of tubular member is designed using line laser scanning principle. The system includes base, swivel table, servo motor, motor driver, servo pack, motor controller, laser displacement sensor, data acquisition card, and computer. The system first gathers the displacement information by laser displacement sensor, then performs coordinate transformation and three dimension reconstruction of the tubular member. The external diameter and the roundness error can also be measured. The experimental results show that the geometric dimensioning parameters measurement is effective and accurate using this method.

• Periodical: Advanced Materials Research (Volumes 655-657)
• Pages: 886-889
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.655-657.886
• Online since: January 2013
• Authors: Jin Jie Yao, Jing Yang, Li Ming Wang, Yan Han, Pei Rui Bai
• Keywords: Automatic Detection, Geometric Dimensioning, Precision Measurement, Roundness Error, Tubular Member

References

[1] H.F.F. Castro. A method for evaluating spindle rotation errors of machine tools using a laser interferometer[J]. Measurement, 2008, 41: 526–537.

DOI: 10.1016/j.measurement.2007.06.002

[2] Zhao W., Tan J., Xue Z. SEST: A new error separation technique for ultra-high precision roundness measurement[J]. Measurement Science and Technology, 2005, 16(3): 833-841.

DOI: 10.1088/0957-0233/16/3/027

[3] Jooho Hwanga, Parka ChunHong, Wei Gao, et al. A three-probe system for measuring the parallelism and straightness of a pair of rails for ultra-precision guide ways[J]. Precision Engineering, 2002, 26: 279–288.

[4] G. L. Samuel and M. S. Shunmugam. Evaluation of Circularity and Sphericity From Coordinate Measurement Data. Journal of Materials Processing Technology, 2003, 139(1-3): 90-95.

DOI: 10.1016/s0924-0136(03)00187-0

[5] Tong Sun. Two-step method without harmonics suppression in error separation[J]. Measurement Science Technology, 2006, 7: 1563-1568.

DOI: 10.1088/0957-0233/7/11/003

[6] Y.Z. Lao, H.W. Leong, F.P. Preparata, G. Singh. Accurate cylindricity evaluation with axis-estimation preprocessing, Precision Engineering, Volume 27, Issue 4, October 2003, Pages 429-437.

DOI: 10.1016/s0141-6359(03)00044-8

[7] Xianqing Lei, Hongwei Song, Yujun Xue, Jishun Li, Jia Zhou, Mingde Duan. Method for cylindricity error evaluation using Geometry Optimization Searching Algorithm, Measurement, Volume 44, Issue 9, November 2011, Pages 1556-1563.

DOI: 10.1016/j.measurement.2011.06.010
