Test Analysis of Vibration Characteristics on CRTS II Slab Ballastless Track Subgrade of the Beijing-Tianjin Intercity High-Speed Railway

Abstract:

Dynamic response tests were developed on CRTS Ⅱslab ballastless track subgrade of Beijing-Tianjin intercity high-speed railway.The relationship between vibration response and the speed, the vertical and horizontal distribution law of vibration response along lines, the effect of axle load on vibration response were researched.Test results are as follows: The vibration displacement of the extreme value caused by a single axle load is not obvious;Train axle load significantly affects the vibration response;Despite the vertical connection between two track slab, but the end of track slab vibration response is still significantly greater than the middle and the vertical multi-storey line structure vibration response decreases rapidly along the depth;Speed has no significant effect on the vibration displacement, but vibration acceleration and vibration velocity is sensitive to speed.

• Periodical: Advanced Materials Research (Volumes 671-674)
• Pages: 1263-1266
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.671-674.1263
• Online since: March 2013
• Authors: Hu Chen, Kun Lin, Sheng Bo Fan, Jian Chen
• Keywords: Ballastless Track, Field Test, High-Speed Railway (HSR), Subgrade, Vibration Characteristics

References

[1] M Sunaga, E Sekine and T Ito: Quarterly Report of RTRI, Vol. 31(1990), p.29.

[2] C. H Goebel and U. C Weisemann: Geotextiles and Geomembranes. Vol. 31(1994)13, p.91.

[3] Leykauf, M Gunther and Lothar. Eisenbahnigenieur. (1990) , p.111.

[4] X. H Chen and W. T Lü: Journal of Vibration and Shock . Vol. 25 (2006) 25 , p.95 (In Chinese).

[5] Z. H Nie, L. Li and B. C Liu: Chinese Journal of Rock Mechanics and Engieering. Vol. 24(2005) 24 , p.1067 (In Chinese).
