Analysis and Study of Solar-Assisted Heat Pump System

Abstract:

Composition and operating modes of two different solar-assisted heat pump systems have been introduced in this paper. The advantages of compound heat pump system are analyzed compared with solo heat pump system. Solar-assisted air source heat pump system not only has the advantages, which air source heat pump system (ASHP) has, but also makes good use of renewable solar energy. It can provide cooling, heating and living hot water all the year. Solar-assisted ground source heat pump system realizes advantage complementation in various seasons between solar heat water system and ground source heat pump (GSHP) system. Solar-assisted ground source heat pump system can adjust the system operating model to solve the disadvantage of sole GSHP system, whose performance decrease for the temperature change of soil for long time operating with annual cool and heat unbalancedness. GSHP system can effectively increase the operating stability with the assistance of solar energy.

• Periodical: Advanced Materials Research (Volumes 671-674)
• Pages: 2122-2125
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.671-674.2122
• Online since: March 2013
• Authors: Qi Wang, Qiang Wang, Xiao Yang Hui, Zhi Jun Shi
• Keywords: Air Source Heat Pump, Ground Source Heat Pump (GSHP), Solar-Assisted Heat Pump System, System Performance

References

[1] Rruicheng Deng, Civil Building Solar Water Heating System Engineering Technical Manuals, Beijing: Chemical Industry Press, 2006 (In Chinese).

[2] M.N. A Hawlader.K. A Jahangeer, Solar heat pump drying and water heating in the tropics, Solar Energy, Vol. 80(5), 2006, pp.492-499.

DOI: 10.1016/j.solener.2005.04.012

[3] Jianhong Li, Baoshan Li, Large Solar Energy Air Conditioning/Heat Pump System Demonstration Applications, Practical Technology, (4), 2004, pp.26-27 (In Chinese).

[4] Yezheng Wu, Guidance for small Refrigeration Equipment Design, Beijing: Mechanical Industry Press, 2006 (In Chinese).

[5] Yuhui Kuang, Sduty of Direct Expansion Solar Assisted Heat Pump Air Conditioning and Water Heating Unit, Shanghai Jiao Tong University, 2004 (In Chinese).

[6] Guoying Xu, Xiaosong Zhang, Analysis on the Operating Characteristics of Solar-Air Source Heat Pump Water Heater, Acta Energiae Solaris Sinica, Vol. 27 (11), 2006, pp.1148-1154 (In Chinese).

[7] Fengzhen Liu, Huanxin Chen, Gaolin Qu, Haisheng Quyang, Analysis of the Heat and Mass Transfer of Frosting Finned Tube Heat Exchanger, Cryogenics, (1), 2004, pp.15-18 (In Chinese).

[8] Shuhong Li, Wenbin Wu, Xiaosong Zhang, Experimental Study and Application Analysis on Solar-Assisted Heat Pump Water Heater Device, Journal of Southeast University (Natural Science Edition), Vol. 35 (1), 2005, pp.82-85 (In Chinese).

[9] Linbin Wei, Qiang Wang, Chuanbo Zhou, A new solar-air compound source heating pump system hanging on balcony, Journal of Shandong Jianzhu University, Vol. 24 (1), 2009, pp.73-77 (In Chinese).

[10] Linbin Wei, Qiang Wang, Haiyun Wang, Simulation and experimental verfication of solar-air compound source heat pump system hanging on balcony, Journal of Shandong Jianzhu University, Vol. 24 (3), 2009, pp.251-255 (In Chinese).
