Evaluation on the Thermal Stresses of a Concrete Slab under Solar Radiation

Abstract:

The time-varying temperature field and stress distribution of a concrete roof slab is actively investigated in this study with the aiding of the commercial package ANSYS. Fine finite element model of the concrete slab is constructed and different boundary conditions are applied to obtain the temperature distribution within the slab. The solar radiation model is utilized to estimate the solar radiation received by the slab and the shelter effects are also taken into consideration. The numerical models can successfully predict the structural temperature gradient and thermal stress distribution at different time. The made observations indicate that the simulated temperature variation of the concrete slab based on the solar radiation model agrees well with measurement results. It is seen that the numerical models can successfully predict the structural time-varying thermal effects.

• Periodical: Advanced Materials Research (Volumes 671-674)
• Pages: 2542-2546
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.671-674.2542
• Online since: March 2013
• Authors: Jian Ping Wang, Bo Chen, Jin Zheng, Peng Yun Li
• Keywords: Concrete Slab, Heat Transfer Analysis, Temperature Distribution, Thermal Stress

References

[1] Kehlbeck F. Einfluss der Sonnenstrahlung bei Bruckenbauwerken. Werner-Verlag, Dusseldorf, Germany, (1975).

[2] Saetta, A. Scotta, R., Vitaliani, R. Stress analysis of concrete structures subjected to variable thermal loads[J], Journal of Structural Engineering ASCE, 1995, 121 (3): 446-457.

DOI: 10.1061/(asce)0733-9445(1995)121:3(446)

[3] Branco, F.A. Mendes, P.A. Thermal actions for concrete bridge design [J], Journal of Structural Engineering ASCE, 1993, 119 (8): 2313-2331.

DOI: 10.1061/(asce)0733-9445(1993)119:8(2313)

[4] Carin, L. John, E. Cawrse, J. Measurements of thermal gradients and their effects on segmental concrete bridge[J], Journal of Bridge Engineering ASCE, 2002, 7 (3): 166-174.

DOI: 10.1061/(asce)1084-0702(2002)7:3(166)

[5] W.M. Rohsenow. Handbook of heat transfer applications. New York: McGraw-Hill, (1988).

[6] Elbadry, M. Ghalli, A. Temperature variation in concrete bridges[J], Journal of Structural Engineering ASCE, 1983, 109 (10): 2355-2374.

[7] Elbadry, M. Ghali, A. Control of thermal cracking of concrete structures[J], ACI Journal, 1995, (7): 435-450.

[8] Dilger, W. H. Ghali, A. Chan, M. Temperature stresses in composite box girder bridges[J], Journal of Bridge Engineering ASCE, 1983, 109 (6): 1460-1478.

DOI: 10.1061/(asce)0733-9445(1983)109:6(1460)

[9] M. Froli, N. Hariga, G. Nati. Longitudinal thermal behavior of a concrete box girder bridge. Structural Engineering International, 1996, 6 (4): 237-242.

DOI: 10.2749/101686696780496139
