Meshing Generation Platform for Industrial Production Models Based on 3D Computational Model

Abstract:

The meshing principles, coefficients and non-uniform meshing for 3D computational model was analyzed and a software platform was developed, containing both uniform and non-uniform meshing and visualization functions. Experiments for industrial production models demonstrated that: the developed platform can achieve good results for both uniform and non-uniform meshing. The implementation of the platform provides a good basis for developing more complete 3D modeling software.
