HomeAdvanced Materials ResearchAdvanced Materials Research Vol. 676Study on Kinematic Features of CNC Machine Based...

Study on Kinematic Features of CNC Machine Based on Multi-Body System Theory with Error Modeling

Abstract:

CNC machine, especially CNC milling machine, is the main production equipment in the industries of mechanics, iron and steel, automobile manufacturing and so on. However, the errors are the main constraints to the processing quality and the precision measurement of CNC machine. Based on the multi-body system theory, the article models the error of Siemens CNC milling machine and kinematic. In terms of the analysis of the error model, it is argued that the processing precision of CNC milling machine can be improved through controlling and compensating the error in the process of installation and manufacturing.
