Synthesis and Optical Properties of Annealed Cr Doped ZnS Nanoparticles

Abstract:

Undoped and Cr doped ZnS nanoparticles with Cr concentrations of 3.0 at.% were prepared by a chemical co-precipitation method for the fist time, using 2-Mercaptoethanol as the capping agent and annealed the synthesized particles at 600°C for 3h in air. The effect of annealing on morphological, structural and optical properties of ZnS and ZnS:Cr have been studied and compared with as prepared samples. EDAX measurements confirmed the presence of Cr in the ZnS lattice and it also confirms the conversion of ZnS into ZnO after annealed at 600 0C/3h. Surface morphologies of all samples were characterized using scanning electron microscopy (SEM). XRD spectra of as synthesized nanoparticles of ZnS and ZnS:Cr exhibited cubic phase. After annealing, the cubic phase is transformed into hexagonal phase. The particle sizes of the ZnS:Cr powders were increased from 5 to 30 nm when the powders were annealed at 600°C. A stable blue emission peak at 445 nm is observed from the as prepared samples (pure ZnS and Cr doped ZnS) but annealed at 600 0C the PL peaked at 500 nm for pure ZnS and Cr doped ZnS nanoparticles exhibited PL peak at 500 nm as well as 654 nm. The emission intensity decreased in annealed particles compared to as synthesized samples.

You might also be interested in these eBooks

Advances in Nanoscience and Nanotechnology

View Preview

Info:

Periodical:

Advanced Materials Research (Volume 678)

Pages:

163-167

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.678.163

Citation:

Cite this paper

Online since:

March 2013

Authors:

D. Amaranatha Reddy, G. Murali, N. Madhusudhana Rao, Vijayalakshmi Raguru, B.K. Reddy

Keywords:

Chemical Method, Green Emission, Red Emission, Zinc Oxide (ZnO), ZnS:Cr

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] Arup K. Rath, Saikat Bhaumik, and Amlan J. Pal, Mn-doped nanocrystals in light-emitting diodes: Energy-transfer to obtain electroluminescence from quantum dots, Appl. Phys. Lett. 97, (2010) 113502-113504.

DOI: 10.1063/1.3489099

Google Scholar

[2] E. Katz, and I. Willner, in Nanobiotechnology, Wiley-VCH (Ed.), Weinheim, 2004.

Google Scholar

[3] J. H. Park, J. Y. Kim, B. D. Chin, Y. C. Kim and O. O. Park, White emission from polymer/quantum dot ternary nanocomposites by incomplete energy transfer Nanotechnol. 15, (2004) 1217-1220.

DOI: 10.1088/0957-4484/15/9/018

Google Scholar

[4] R.N. Bhargava, D. Gallagher, Optical Properties of Manganese-Doped Nanocrystals of ZnS,Phys. Rev. Lett. 72, (1994) 416-419.

DOI: 10.1103/physrevlett.72.416

Google Scholar

[5] N. Kumbhojkar, V. V. Nikesh, A. Kshirsagar and S. Mahamuni, Photophysical properties ofZnS nanoclusters, J. Appl. Phys. 88 (2000) 6260-6264.

DOI: 10.1063/1.1321027

Google Scholar

[6] Baibaswata Bhattacharjee, Chung-Hsin Lu, Multicolor luminescence of undoped zinc sulfide nanocrystalline thin films at room temperature, Thin Solid Films 514 (2006) 132 – 137.

DOI: 10.1016/j.tsf.2006.02.096

Google Scholar

[7] Benedikt Steitz, Yvonne Axmann, Heinrich Hofmann, Alke Petri-Fink, Optical properties of annealed Mn2+-doped ZnS nanoparticles J. Lumin. 128 (2008) 92–98.

DOI: 10.1016/j.jlumin.2007.05.014

Google Scholar

[8] S. Saravana Kumar, M.Abdul Khadar, K.G.M. Nair, Analysis of the effect of annealing on the photoluminescence spectra of Cu+ ion implanted ZnS nanoparticles, J. Lumin. 131 (2011) 786–789.

DOI: 10.1016/j.jlumin.2010.12.004

Google Scholar

[9] S. Sambasivam , B.K. Reddy, A. Divya, N. Madhusudhana Rao, C.K. Jayasankar, B. Sreedhar, Optical and ESR studies on Fe doped ZnS nanocrystals, Phys. Lett. A 373 (2009) 1465–1468.

DOI: 10.1016/j.physleta.2009.02.032

Google Scholar

[10] D. Amaranatha Reddy, G. Murali, R. P. Vijayalakshmi, B. K. Reddy, and B. Sreedhar, Cryst. Res. Technol. 46, (2011) 731 – 736.

DOI: 10.1002/crat.201100146

Google Scholar

[11] M.M. Biggs, O.M. Ntwaeaborwa, J.J. Terblans, H.C. Swart, Characterization and luminescent properties of SiO2:ZnS:Mn2+ and ZnS:Mn2+ nano phosphors synthesized by a sol–gel method, Physica B 404 (2009) 4470–4475.

DOI: 10.1016/j.physb.2009.09.048

Google Scholar

[12] Rizwan Wahab, S. G. Ansari, Young-Soon Kim, M. S. Dhage, Hyung Kee Seo, Minwu Song and Hyung-Shik Shin, Effect of Annealing on the Conversion of ZnS to ZnO Nanoparticles Synthesized by the Sol-Gel Method Using Zinc Acetate and Thiourea, Met. Mater. Int., 15 (2009) 453-458.

DOI: 10.1007/s12540-009-0453-5

Google Scholar
