Seismic Performance of Moment End-Plate Connections to CFT Column under Cyclic Loading

Abstract:

An experimental program under cyclic load is performed on two half-scale interior moment end-plate connections to concrete filled tubular (CFT) columns. Flat and curved stiffened extended end-plates were welded to the steel beams in the shop, and bolted on the site to the square and circular CFT column tubes respectively, using steel rods passing through the column. The experimental results demonstrated that both circular and rectangular end-plate connections showed similar performance in a ductile manner and the stiffener elements were effective to form the plastic hinges away from the welding zone, also the proposed curved end-plate connection with rods passing through the column in “X” shape was effective. The test specimens showed a plastic rotations capacity of 0.054 radian.

• Periodical: Advanced Materials Research (Volume 680)
• Pages: 205-210
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.680.205
• Online since: April 2013
• Authors: Ikhlas S. Sheet, Umarani Gunasekaran
• Keywords: Concrete-Filled Steel Tube (CFST), Moment End-Plate Connection, Seismic Performance

References

[1] SM. Takhirov, EP. Popov, Bolted large seismic steel beam-to-column connections Part 2: Numerical nonlinear analysis, Engineering Structures. 24 (12) ( 2002) 1535-1545.

DOI: 10.1016/s0141-0296(02)00087-1

[2] HG. Prion, AB. McLellan, Connecting steel beams to concrete-filled steel columns, Proceedings of ASCE Structures Congress on Composite Compression Members, San Antonio, TX, 1992, pp.918-921.

[3] SW. Peng, JM. Ricles, R. Sause, LW. Lu, Experimental evaluation of a post- tensioned moment connection for steel and composite frames in seismic zone, In: Xiao, Mahin, editors. Composite and hybrid structures-Proceedings of 6th ASCCS conference, 2000, pp.721-728.

DOI: 10.1201/9781003211198-32

[4] JM. Ricles, SW. Peng, LW. Lu, Seismic behavior of composite concrete filled steel tube column-wide flange beam moment connection, Journal of Structural Engineering. 130(2) (2004) 223-232.

DOI: 10.1061/(asce)0733-9445(2004)130:2(223)

[5] X. Li, YT. Wu, WF. Mao, Y. Xiao, JC. Anderson, YR. Guo, Bolted end plate connections for steel reinforced concrete composite structures, Structural Engineering and Mechanics. 24(3) (2006) 291-306.

DOI: 10.12989/sem.2006.24.3.291

[6] LL. Chung, LY. Wu, GL. Huang, CF. Lu, DH. Huang, Experimental studies on the design parameters of bi-directional bolted beam-column connections for concrete filled-tube structures, Report no.: NCREE 04-002. National Centre for Research on Earthquake Engineering. (2004).

[7] LY. Wu, LL. Chung, SF. Tsai, CF. Lu, GL. Huang, Seismic behaviour of bolted beam to column connections for concrete filled steel tube, Journal of Constructional Steel Research. 61(10) (2005) 1387-1410.

DOI: 10.1016/j.jcsr.2005.03.007

[8] LY. Wu, LL. Chung, SF. Tsai, CF. Lu, GL. Huang, Seismic behaviour of bidirectional bolted connections for CFT columns and H-beams, Journal of Engineering Structures. 29 (3)(2007) 395-407.

DOI: 10.1016/j.engstruct.2006.05.007

[9] American Institute of Steel Construction AISC. Prequalified connections for special and intermediate steel moment frames for seismic applications. ANSI/AISC (358s1-11 and 358-10). Chicago, IL. (2011).

DOI: 10.1061/40889(201)5

[10] American Institute of Steel Construction AISC. Seismic provision for structural steel buildings. Chicago, IL. (2002).
