Analysis of Wave Loads on Pile-Group Foundation

Abstract:

The grouping pile foundation is widely used in the construction of bridge over sea and its scale of construction is generally dominated by the wave force on the pile groups. Because of the presence of the slab, not only the incident wave but also the diffraction wave should be considered in calculating wave loads on pile groups. The diffraction from a submerged circular cylinder representing the slab was taken as an example, and wave loads on piles in the diffraction wave field were calculated by using Morison formula. Results show that the effect of slab decreases with the increase of incident wave number. Changing laws of different piles in the pile-group foundation varied with the submerged depth. Wave loads at the meeting-wave side of slab is larger than the back side of that. And the presence of slab caused the deflexion of inline force. The grouping piles coefficient can be taken as 0.7.

• Periodical: Advanced Materials Research (Volume 680)
• Pages: 217-221
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.680.217
• Online since: April 2013
• Authors: Yi Min Liu
• Keywords: Effect of Slab, Pile Groups, Submerged Circular Cylinder, Wave Force

References

[1] B.L. Geng, B. Teng, D.Z. Ning, et al, A time-domain in analysis of wave force on small-scale cylinders of platform under freak waves, Journal of Dalian Maritime University, 1 (2010) 39-43.

[2] Y. M Lan, L.P. Xue, H. Liu, et al, Experimental studies on hydrodynamic loads on piles and slab of Donghai Bridge, Part I: hydrodynamic forces on a single pile in wave-current combinantions, Journal of Hydrodynamics, Ser. A, 6 (2004) 753-758.

[3] Y. M Lan, H. Liu, F.X. Huang, et al, Experimental studies on hydrodynamic loads on piles and slab of Donghai Bridge, Part II: hydrodynamic forces on pile array and slab in wave-current combinantions, Journal of Hydrodynamics, Ser. A, 3 (2005).

[4] S.X. Liu, Y.C. Li and G.W. Li, Wave current forces on the pile group of base foundation for the East Sea Bridge, China, Journal of Hydrodynamics, Ser. B, 19 (2007) 661-670.

DOI: 10.1016/s1001-6058(08)60001-3

[5] W. W Yao , H. Liu, Effect of circular slab fo wave loads on piles in regular waves, Journal of Chinese Quarterly of Mechanics, 3 (2009) 357-362.

[6] B.L. Geng, B. Teng and D.Z. Ning, A time-domain analysis of wave force on small-scale cylinders of offshore structures, Journal of Marine Science and Technology, 18 (2010) 875-882.

DOI: 10.51400/2709-6998.1946

[7] W. Lai, Study on dynamic response of deep-water bridges under earthquake and wave, P.D. Dissertation, Dept. of Civil Eng., Tongji University, Shanghai, (2004).
