Experimental Device of Drilling String Dynamics in Horizontal Well and its Application

Abstract:

According to the principle of similitude, a simulation experimental device for investigating drilling string dynamics in horizontal well was designed and set up. The rotary speed, WOB, drilling string lateral displacement, bottom hole WOB fluctuations and lateral force of the bit, etc. can be measured under different WOB and rotary speed by the experimental device; Some debugging experiments have been done by means of the device under different weights on bit and rotary speeds. The simulated experiment has many advantages comparing to the actual experiment, such as less operators, less times and moneys. It is easy to operate, the drilling string movement can be visually observed and all of the experimental results can be used to the actual drilling.

• Periodical: Advanced Materials Research (Volume 683)
• Pages: 690-693
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.683.690
• Online since: April 2013
• Authors: Dong Dong Shao, Zhi Chuan Guan, Xin Wen
• Keywords: Dynamic, Experimental Research, Horizontal Well, Lateral Force of Bit, Rotary Speed, WOB

References

[1] Wolf S F, Zacksenhouse M, Arian A. Filed measurements of down hole drilling vibration. SPE14330, 1985: 22-26.

[2] Zhang Yang-lie. Drill string dynamics and kinematics. Beijing: Petroleum Industry Press, 2001: 30-89.

[3] Gao Baokui, Gao Deli, Xie Jinwen. Drill string whirling and its application. Journal of University of Petroleum (Edition of Natural Science), 1997, 21(1): 25-27.

[4] Millheim K K, Apostal M C. How BHA dynamics affect on bit trajectory. World Oil, 1981, 92(6): 183-205.

[5] Allen M B. BHA lateral vibrations: case studies and evaluation of important parameters. SPE16110, 1987: 15-18.

DOI: 10.2118/16110-ms

[6] Li Zhiguang. Similarity and modularization. Beijing: National Defence Industry Press, 1982: 16-35.

[7] Zheng Mingxin. Engineering materials. Beijing: Tsinghua University Press, 1991: 25-37.

[8] Guan Zhichuan, Jin Yanxin, Wang Yifa. Experimental research on motion behavior of bottom drill string in straight hole. Acta petrolei sinica, 2003, 24（6）: 102-106.

[9] Shi Yucai, Yuan Yanyan, Wu chunfang. Setting up a simulate device on motion behavior of bottom-hole assembly according to similitude principles. Journal of Guangxi University(Natural Science Edition). 2006, 31(supplement): 159-162.

[10] Shi Yucai, Wang Jun, Guan Zhichuan. Research on whirling mechanism of bottom drill string and its rules by inner simulated experiments. Journal of Guangxi University(Natural Science Edition). 2007, 32(2), 126-129.
