The Analysis of the Influencing Factors about Friction and Wear Characteristics of the Piston Ring in Stirling Engine

Abstract:

The problem about friction and wear characteristics of piston ring which is directly related to the sealing properties of stirling engine was analyzed. An improved seal structure of piston ring was taken as the research object, the influence of the temperature and the pressure of refrigerant were considered when the friction and wear characteristics of piston ring in stirling engine was studied. The calculation formula about radial weal amount of the piston ring with the change of the temperature and the gas pressure was derived by using the peeling wear theory. Then, the experiment was taken to confirm these formulas. The results show that the formulas were right. Hence, a viable way to analysis the sealing properties and life prediction method of piston rings was got.

• Periodical: Advanced Materials Research (Volumes 690-693)
• Pages: 2003-2007
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.690-693.2003
• Online since: May 2013
• Authors: Dong Ya Yang, Huan Xie, Jun Gong
• Keywords: Friction, Piston Ring, Stirling Engine, Volume of Wear Loss, Wear

References

[1] Dongya Yang, Zhenning Lei, Jun Gong et al. Research on the Clearance Seal in Sterling Refrigerator. Advanced Materials Research, 2012, (510):54-58.

DOI: 10.4028/www.scientific.net/amr.510.54

[2] Glushenkov, Maxim. Single-piston alternative to Stirling engines. Applied Energy, 2009, (97):743-748.

DOI: 10.1016/j.apenergy.2011.12.050

[3] Berggren, Robert W; Moynihan. Effects of displacer seal clearance on free-piston stirling engine performance. Proceedings of the Intersociety Energy Conversion Engineering Conference, v 4, 1982:1885-1891.

[4] Zhu Yu-feng. Research on Design of Integral Non-backpressure Piston Rings in Compressors. Lubrication Engineering, 2006, (12):106-107.

[5] Zhang Yong, Qiu Xue-tang, Mo Sen-quan. Research on Seal Performance of a New Type of Composite Piston Ring. Transactions of CSICE, 2010, (3):281-287.

[6] Zhu Yu-feng. Design and calculation on work clearance and relative interference amount of none—backpressure piston rings. Journal of Hebei University of Science and Technology 2008, 29(1):53-56.

[7] Wen Shi-zhu, Huang Ping. Principles of Tribology. BeiJing: QingHua University Press, 2008:302-303.

[8] Peng Bao-cheng, Zhu Yu-feng. Study on Elastic Force Ring for Sealing and Life of the Piston Ring. Lubrication Engineering, 2006, (8): 97-99.

[9] Chen Geng, Jiao Gui-long, Lu Ding-ji.Design of the tribology of Piston Ring in Oil-free Compressor. Machine Design and Research, 1989, (2):2-8.
