Finite Element Analysis of Sealing Structures for SF6 Gas Insulated Switchgear

Abstract:

The sealing equipment of the SF6 GIS including the rubber O-ring and bolts were numerically simulated. Effects of bolts number, the tension moment of bolts, and gas pressure on contact stress and peak stress of O-ring were mainly studied. Simulated results showed that the bolts number and tension moment of bolts has a great effect on the sealing performance of mechanical seal and the maximum stress of O-ring. The higher contact pressure could be achieved under the condition of a larger bolts tension moment and bolts number and smaller gas pressure, but it also results in a reduce of life of O-ring.

• Periodical: Advanced Materials Research (Volumes 690-693)
• Pages: 2738-2741
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.690-693.2738
• Online since: May 2013
• Authors: Chun Li, Feng Ying, Hua Zhao
• Keywords: Finite Element Analysis (FEA), GIS, Rubber O-Ring, Sealing

References

[1] YE Zhen-xia, YE Li-min, Zhu Hai-chao. A FEM analysis method of hyper-elastic contact problem for sealing strucrure, Journal of naval university of engineering, Vol.17 No.1, (2005)

[2] ABAQUS 6.11-1 HTML Documentation

[3] Zhuang zhuo. ABAQUS finite element analysis and application. Tsinghua University press. 2011, p.450

[4] Wang Yong-guan, Huang You-jian. The choice of the constitutive model of rubber simulation.Fourth national rubber products technology seminar, (2007)
