Inaln/GaN HEMT Small-Signal Parameter Extraction

Abstract:

We use S-Parameter Methodto extract device parameter of InAlN/GaN HEMT in this paper. We find thatparasitic capacitance and parasitic inductance can be extracted in traditionaltest structure method, but do nothing about parasitic resistor. Cold parameter methodcan extract parasitic resistor efficiently, but there is greater error inparasitic capacitance and parasitic inductance extraction. We propose a methodwhich combines test structure method and cold parameter method to extract parasitic parameteraccurately. We can acquire intrinsic parameters through getting rid ofparasitism parameters, and can fitting test outcome satisfactorily. It canreflect accurately the physical characteristics of GaN HEMT devices, and givesfeedback and guidance to device technology at the same time.

• Periodical: Advanced Materials Research (Volumes 690-693)
• Pages: 564-568
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.690-693.564
• Online since: May 2013
• Authors: Xiao Wei Zhang, Peng Xu*, Ke Jin Jia, Zhi Hong Feng, Zheng Ping Zhao
• Keywords: Parasitic Capacitance, Parasitic Inductance, sGaN HEMT

References

[1] 12 Microwave Power Performance N-Polar GaN MISHEMTs Grown by MOCVD on SiC Substrates UsinganAl2O3 Etch-Stop Technology

DOI: 10.1109/led.2011.2173458

[2] 11 RF performance of InAlN_AlN_GaN HEMTs on sapphire substrate

[3] Medjdoub, F., Carlin, J.F., Gaquiere, C., Grandjean, N., and Kohn, E.:'Status of the emerging InAlN/GaN power HEMT technology', Open Electr. Electron. Eng. J., 2008, 2, p.1–7

DOI: 10.2174/1874129000802010001

[4] Haifeng, S., Alt, A.R., Benedickter, H., Feltin, E., Carlin, J.-F., Gonschorek, M., Grandjean, N.R., and Bolognesi, C.R.: '205-GHz (Al,In)N/GaN HEMTs', IEEE Electron Device Lett., 2010, 31, (9), p.957–959

DOI: 10.1109/led.2010.2055826

[5] Sarazin, N., Morvan, E., di Forte Poisson, M.A., Oualli, M., Gaquiere, C., Jardel, O., Drisse, O., Tordjman, M., Magis, M., and Delage, S.L.: 'AlInN/AlN/GaN HEMT technology on SiC with 10-W/mm and 50% PAE at 10 GHz', IEEE Electron Device Lett., 2010, 31, (1), p.11–13

DOI: 10.1109/led.2009.2035145

[6] 2000Determination of Small-Signal Parameters of GaN-based HEMTs

[7] Direct extraction of the AlGaAs GaAs heterojunction bipolar transistor small-signal equivalent circuit

[8] A new method for determining the FET small-signal equivalent circuit

[9] 94Conversions between S, Z, Y, h, ABCD, and T parameters which are valid for complex source and load impedances

[10] High frequency equivalent circuit of GaAs FET's for large signal applications
