Design of Test System for X Aero-Engine Synthesis Adjuster

Abstract:

Based on the use of exiting testing equipment research, summarize the request of detection and analyze the existing problems. According to the signal characteristics of the aero-engine synthesis adjuster, designed a kind of test system based on virtual instrument for it, and developed a software system used for the adjuster in situ detection and offline testing. National Instruments launched Compact RIO platform. Adopted this platform as hardware system can realize test system open and integration designed very well, and simulated sensors for the offline test part of the system. This test system realized parameters calibrating, channel testing and fault diagnosis function etc. for the adjuster.

• Periodical: Advanced Materials Research (Volumes 694-697)
• Pages: 1202-1206
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.694-697.1202
• Online since: May 2013
• Authors: Yi Lin Zhou, Tong Hua Zhang, Bin Gong
• Keywords: Aero-Engine, Synthesis Adjuster, Test System, Virtual Instrument (VI)

References

[1] Zheng Wang, Jianhua Song, and Zhi Qiu: Metrology & Measurement Technology Vol. 31, No.2 (2011), pp.17-20. In Chinese

[2] Shengliang Zhang, Shousheng Xie: Journal of Propulsion Technology Vol. 24, No.2 (2003), pp.190-192. in Chinese

[3] Min Ma, Guangju Chen: Journal of Electronic Science and Technology of China Vol. 3, No.2 (2005), pp.157-160.

[4] Xiaozhen Xia, Zujun Yu, Jianfeng Mao and Yudong Zou: Journal of china ordnance Vol. 2, No.3 (2006), pp.157-160.

[5] Shufen Qi, Ning Liu: Design of engine electronic controller detection system based on PXI bus, IEEE International Conference on Automation and Logistics (ICAL) (2012).

DOI: 10.1109/ical.2012.6308202

[6] Gang Tong: Virtual instrument practical programming technology (China Machine Press, Beijing 2008).In Chinese

[7] Information on http://bbs.gsdzone.net/
