Determination of TDC Using Digital Correlation Method for Linear Compressor

Abstract:

Moving-magnet linear compressors with sensorless top dead center (TDC) control method are an efficient solution for domestic refrigerators to save energy. TDC can be determined by the inflection point of phase difference between the sinusoidal current and piston displacement (I-X phase difference). A digital correlation method is used to calculate the I-X phase difference to obtain the TDC position for control. The TDC determining system using digital correlation method is manufactured and the error is 2.29% under various discharge pressures.

• Periodical: Advanced Materials Research (Volumes 694-697)
• Pages: 1608-1614
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.694-697.1608
• Online since: May 2013
• Authors: Guo Hong Peng, Ming Sheng Tang, Hui Ming Zou, Chang Qing Tian, Xu Chen
• Keywords: Digital Correlation Method, Linear Compressor, Moving-Magnet, Phase Difference, TDC
