Design of Belt Conveyor Based on Dual Mode Modeling Approach of CAXA

Abstract:

This paper proposes a dual-mode modeling technology based on software- Computer Aided X Alliance (CAXA), and verifies the method with a belt conveyor as an example. The purpose of dual-mode modeling technology integrating innovation design pattern and engineering design pattern is to achieve a fusion between open design and accuracy design technology. Dual-mode modeling approach breaks single thought constraint owned by traditional parametric modeling, which has a strict relationship like father and son between part elements. By means of design example, this paper described the help that unique three-dimensional sphere functions only owned by CAXA give the solid modeling. This paper took belt conveyor for an example, introduced dual-mode modeling process and verified this approach. Combined with the help of the idea of modular design, this paper has accomplished assembly design of the driving motor module, roller device module and transmission device module. The results show that the design speed under the condition of dual-mode modeling can improve more than one time compared with the traditional methods, design error is greatly reduced and design efficiency is also greatly advanced.

• Periodical: Advanced Materials Research (Volumes 694-697)
• Pages: 3101-3104
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.694-697.3101
• Online since: May 2013
• Authors: Bin Hua, Yi Lin Chi, Xue Jun Wang, Fu Yu Li
• Keywords: Belt Conveyor, CAXA, Dual-Mode Modeling Approach, Modular Design, Standardization Design

References

[1] YuefengLeng,JiaLiu,Feng Zu: Advanced Materials Research.vol56-157(2011),p.1243

[2] C.T. Kianoudis,Z.B .Maroulis,D.Marinos-Kouris:Journal of Food Engineering.vol23 (1994), p.375

[3] Yakui Li, Hongwei Li, Hanqing Liu: submitted to CCPR 2008. p.106 (2008)

[4] GuangbuLi, RuqiongLi: submitted toSecond international confernce on information and computing science. vol4 (2009). p.304.

[5] Xuejun Wang, Yilin Chi, Fuyu Li, Li Gao, Yongxin Peng. The Research of Industrial Robots Design Based on Synchronous Technology. Applied Mechanics and Materials. Vols. 233, in 2012, pp.347-350.

DOI: 10.4028/www.scientific.net/amm.233.347

[6] Xuejun Wang, Yilin Chi, Li Gao. Study on the Design of Corner Conveyor Driven by "V" Belt with Friction. Applied Mechanics and Materials. Vols. 233, in 2012, pp.351-354.

DOI: 10.4028/www.scientific.net/amm.233.351

[7] Xuejun Wang, Yilin Chi, Fuyu Li, Li Gao, Ping Xu. Study on Parametric Design of Roller Conveyor Based on Top-Down Assembly Modeling Technology. Applied Mechanics and Materials. Vols. 233, in 2012, pp.361-364.

DOI: 10.4028/www.scientific.net/amm.233.361

[8] Information on http://www.ug888.com/list.asp?ProdId=1243

[9] Information on http://www.mouldbbs.com/thread-33639-1-1.html

[10] Xin Wu, Changlong Du, JiaJia Zhang: Coal Mine Machinery.vol.31 (2010), p.59 (In Chinese)
