Mechanical and Hydraulic Joint Modeling and Simulation about Elec-Pump

Abstract:

Elec-pump (electric-hydraulic-pump) is a highly integrated combination of electric motor and hydraulic pump, which has smaller size, lower noise and vibration, better heat elimination, and has broad application prospects. In this paper, an elaborately parameterized model of the axial piston Elec-pump is built for the mechanical and hydraulic joint simulation by using the simulation software AMESim and ADAMS. The joint model is composed of the electromagnetic drive model, hydraulic model, the mechanical dynamics model and the mechanical hydraulic interface. The joint simulation shows how the rotor centroid pulsation affects the output pressure of Elec-pump at different outlet pressures. The results depicts that, due to the rotor centroid pulsation, the outlet pressure pulsation rate becomes more than doubled at the revolution of 7000rev/min.

• Periodical: Advanced Materials Research (Volumes 694-697)
• Pages: 614-620
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.694-697.614
• Online since: May 2013
• Authors: Yong Ling Fu, Zhu Feng Li, Peng Zhang, Huan Ming Chen
• Keywords: Elec-Pump, Mechanical and Hydraulic Joint Simulation Modeling and Simulation, Motor Pump, Pressure Fluctuate Rate, Rotor Centroid Pulsation

References

[1] Yongling Fu, Zhufeng Li and Gaocheng An: Machine Tool and Hydraulics, Vol.1(2012), p.143 (In Chinese)

[2] Allan A. Voight, U.S. Patent 4,850,812. (1989)

[3] Harry C., Moon Jr., U.S. Patent 5,220,225. (1993)

[4] Kazunori Kawafune, U.S. Patent 5,591,013. (1997)

[5] Gerd Hundr and Franz Arbogast, U.S. Patent 7,381,036 B2. (2004)

[6] Minzong Huang, Youzhang Wu and Shengping Xie: Mechanical Monthly, Vol.8(2005), pp.143-150. (In Chinese)

[7] Hong Ji and Zhifeng Li: Transactions of the Chinese Society for Agricultural Machinery, Vol.11(2010), p.48 (In Chinese)

[8] Dianrong Gao and Jinhui Liu: Hydraulic and Pneumatic, Vol.1(2011), p.55 (In Chinese)

[9] YANG Haodong, LI Rong and LIU Weiguo: Mathematical Model and Simulation of Brushless DC Motor [J]. Micro Motors, Vol.4(2003), p.8 (In Chinese)

[10] Cunxing He: Hydraulic components, Machinery Industry Press(1981) (In Chinese)

[11] Weidong Guo and Zhanlin Wang: Journal of Beijing University of Aeronautics and Astrnautics, Vol.2(1996), p.225 (In Chinese)

[12] Bin Zhang: Study on Virtual Prototype and Pressure Characteristics of Oil Film for Axial Piston Pump. Doctoral Dissertation from Zhejiang University, 2009, p.103 (In Chinese)
