A Study on the Bending Analysis of the Al Honeycomb Core Sandwich Composite Panel Bearing Large Bending Load

Abstract:

Al honeycomb core sandwich composite panels have different core and plate materials. The core is the Al honeycomb core, and the thin plate is GFRP sheets with fibers laminated in the 0°/90° symmetric structure. The Al honeycomb core sandwich composite panel is used for structures, which involve relatively high bending load. Before designing the structures, their stability is evaluated via the finite element analysis. In this study, an analysis method that is closest to the reality was proposed for designing the structures with Al honeycomb core sandwich composite panels. For that purpose, the modulus was reviewed. In the finite element analysis, the tensile modulus is generally used. In the results of this study, however, the tensile modulus led to significant deviations from the test results, whereas the bending modulus led to a closer value to the test results.

• Periodical: Advanced Materials Research (Volume 702)
• Pages: 245-252
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.702.245
• Online since: May 2013
• Authors: Hong Gun Kim, Young Jun Kim, Hee Jae Shin, Sun Ho Ko, Hyun Woo Kim, Young Min Kim, Yun Ju Cha, Woo Kum Lee, Lee Ku Kwac
• Keywords: Al Honeycomb Core Sandwich Composite Pannel, Bending Modulus, Bending Tests, Finite Element Method (FEM), Tensile Modulus

References

[1] Vinson, J. R: He behavior of sandwich structures of isotropic and composite materials(1999), pp.1-9

[2] Shin K. B, Koo D. H, Hahn S. H, Park K. J: A Study on Material Selection of the Carbody Structure of Korean Tilting Train eXpress(TTX) through the Verification of Design Requirements ,Journal of the Korean Society for Railway, Vol.7, No.2 (2004), pp.77-84

[3] Shin K. B, Lee J. Y, Lee S. J: A Study on Low-Velocity Impact Characterization of Various Sandwich Panels for the Korean Low Floor Bus Application, Journal of The Korean society for mechanical Engineers, Vol.31, No.4 (2007), pp.506-516

DOI: 10.3795/ksme-a.2007.31.4.506

[4] Shin K. B., Lee J. Y., Ryu B. J., and Lee S. J: A Study on Flexural Behaviors of Sandwich Composites with Plates of Unequal Thickness, Journal of the Korean Society for Railway, Vol.10, No.2 (2007), pp.201-210

[5] ASTM C393: Flexural properties of sandwich constructions (2000)
